Eaton Moeller series xComfort dimming actuator

Name: Eaton Moeller series xComfort dimming actuator
Brand: Eaton
SKU: 110778

رقم القطعة: 110778

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller series xComfort dimming actuator

Functions	Bus module detachable
Product Name	Eaton Moeller series xComfort dimming actuator
Catalog Number	110778
Model Code	CDAU-01/03
EAN	4015081103256
Product Length/Depth	75 mm
Product Height	27 mm
Product Width	60 mm
Product Weight	0.049 kg
Compliances	RoHS conform CE Marked
Source URL	https://www.eaton.com/gb/en-gb/skuPage.110778.html
Features	Local operation/hand operation Radio frequent bidirectional
Degree of protection	IP20
Width in number of modular spacings	3
Mounting method	Flush mounting Flush mounted (plaster)
Model	Dimming actuator
Fitted with:	Bus connection LED indication
Voltage rating - max	230 V
Bus system operating type	Radio frequent Other
Power supply	Mains
Bus system product type	Actuator
Actuation function	Dimming
Frequency rating - max	50 Hz
Frequency rating - min	0 Hz
Output power - max	125 W
Output power - min	0 W
Rated control supply current Is	0 mA
Voltage rating - min	0 V
Number of outputs	1
Load type	Capacitive
