Eaton XC Modular PLC

Name: Eaton XC Modular PLC
Brand: Eaton
SKU: 134238

رقم القطعة: 134238

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton XC Modular PLC

المواصفات

Ambient operating temperature - max	55 °C
Ambient operating temperature - min	0 °C
Ambient storage temperature - max	70 °C
Ambient storage temperature - min	-25 °C
Functions	Overvoltage protection Additional program memory possible
Product Name	Eaton XC Modular PLC
Catalog Number	134238
Model Code	XC-CPU202-EC4M-8DI-6DO-XV
EAN	4015081311088
Product Length/Depth	100 mm
Product Height	100 mm
Product Width	60 mm
Product Weight	0.25 kg
Certifications	EN 50178 IEC/EN 61131-2 EAC
Source URL	https://www.eaton.com/gb/en-gb/skuPage.134238.html
Features	Mains filter (power supply) Asynchronous, cyclic, acyclic PDO types (CANopen®) Mains overvoltage protection (power supply) Expandable with XI/OC expansions Short-circuit protection (power supply) Integrated Web server
Type	Modular PLC XC-CPU202
10.10 Temperature rise	The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data for the devices.
10.11 Short-circuit rating	Is the panel builder's responsibility.
10.12 Electromagnetic compatibility	Is the panel builder's responsibility.
10.13 Mechanical function	The device meets the requirements, provided the information in the instruction leaflet (IL) is observed.
10.2.2 Corrosion resistance	Meets the product standard's requirements.
10.2.3.1 Verification of thermal stability of enclosures	Meets the product standard's requirements.
10.2.3.2 Verification of resistance of insulating materials to normal heat	Meets the product standard's requirements.
10.2.3.3 Resist. of insul. mat. to abnormal heat/fire by internal elect. effects	Meets the product standard's requirements.
10.2.4 Resistance to ultra-violet (UV) radiation	Meets the product standard's requirements.
10.2.5 Lifting	Does not apply, since the entire switchgear needs to be evaluated.
10.2.6 Mechanical impact	Does not apply, since the entire switchgear needs to be evaluated.
10.2.7 Inscriptions	Meets the product standard's requirements.
10.3 Degree of protection of assemblies	Meets the product standard's requirements.
10.4 Clearances and creepage distances	Meets the product standard's requirements.
10.5 Protection against electric shock	Does not apply, since the entire switchgear needs to be evaluated.
10.6 Incorporation of switching devices and components	Does not apply, since the entire switchgear needs to be evaluated.
10.7 Internal electrical circuits and connections	Is the panel builder's responsibility.
10.8 Connections for external conductors	Is the panel builder's responsibility.
10.9.2 Power-frequency electric strength	Is the panel builder's responsibility.
10.9.3 Impulse withstand voltage	Is the panel builder's responsibility.
10.9.4 Testing of enclosures made of insulating material	Is the panel builder's responsibility.
Degree of protection	IP20
Mounting method	Wall mounting/direct mounting Rail mounting possible
Number of modules	Max. 126
Model	Modular
Fitted with:	Real time clock
Mounting position	Horizontal
Shock resistance	15 g, Mechanical, Shock duration 11 ms
Vibration resistance	57 - 150 Hz, ± 1.0 g 10 - 57 Hz, ± 0.075 mm
Equipment heat dissipation, current-dependent Pvid	0.08 W
Heat dissipation capacity Pdiss	0 W
Heat dissipation per pole, current-dependent Pvid	0 W
Rated operational current for specified heat dissipation (In)	0 A
Static heat dissipation, non-current-dependent Pvs	6 W
Connection type	RJ45, Ethernet Plug-in terminal block, CANopen® Plug-in terminal block
Pollution degree	2
Overvoltage category	II
Rated impulse withstand voltage (Uimp)	850 V (auxiliary and control circuits)
Accessories	Order terminal clamps, module rack and battery separately.
Voltage type	DC
Rated operational current (Ie)	0.5 A at AC-3, 230 V
Operating mode	Watchdog
Explosion safety category for dust	None
Explosion safety category for gas	None
LED indicator	Status indication of Power supply of local inputs/outputs: LED
Memory capacity	4,000 kByte
Memory type	RAM
Memory	64 kByte Retain Memory 512 kByte Program memory data 4 MByte Program memory code 16 kByte Marker Memory 4 MByte (User memory)
Number of outputs	6 (transistor outputs)
Power loss	6 W Normally 85 mW
Relative humidity	10 - 95 % (non-condensing)
Switching capacity	IEC/EN 60947-5-1, utilization category DC-13, Digital outputs
Protocol	PROFIBUS MODBUS SUCONET EtherNet/IP Other bus systems CANopen® (To DS 301 V4) TCP/IP CAN
Input voltage	24 V DC (Power supply of local inputs/outputs) 24 V DC (Power supply)
Air pressure	795 - 1080 hPa (operation)
Bus termination	Internal, CANopen®
Output voltage	5 V DC (signal module)
Output current	3.2 A
Battery runtime	5 years typ.
Number of channels	6
Safety performance level (EN ISO 13849-1)	None
SIL (IEC 61508)	None
Input power	33 W
Making/breaking delay	0.1 ms
Number of HW-interfaces (industrial ethernet)	1
Number of HW-interfaces (other)	1
Number of HW-interfaces (parallel)	0
Number of HW-interfaces (RS-232)	1
Number of HW-interfaces (RS-422)	0
Number of HW-interfaces (RS-485)	0
Number of HW-interfaces (USB)	1
Number of HW-interfaces (wireless)	0
Number of interfaces (PROFINET)	0
Number of outputs (analog)	0
Duty factor	100 %, Digital outputs
Supply voltage	20.4 - 28.8 V DC
Emitted interference	Class A (according to IEC/EN 61000-6-4)
Interference immunity	According to EN 61000-6-2
Protection against polarity reversal	Yes Yes, for AS-Interface
Number of inputs (analog)	0
Cycle time	< 0.025 ms, for 1 k of instructions (Bit, Byte), memory
Number of outputs (digital)	6
Data transfer rate	1 MBit/s, CANopen® 10/100 MBit/s, autodetect, Ethernet 115.2 kBit/s, Serial interface (RS232) without handshake lines
Number of relay outputs	0
Delay time	0.1 ms typ., Output delay, On -> Off 0.1 ms typ., Digital inputs, Delay time from 0 to 1, Debounce OFF 0.1 ms typ., Digital inputs 24 V DC, Delay time from 1 to 0, Debounce OFF
Residual ripple	≤ 5 %
Inrush current	No limitation (limited only by upstream 24 V DC power supply unit)
Input current	3.5 mA (per channel at nominal voltage, Digital inputs)
Processor	ARM 532 MHz
Number of time switches - max	1000
Processing time	0.025 ms
Repetition rate	1 s
Supply voltage at AC, 50 Hz - max	0 VAC
Supply voltage at AC, 50 Hz - min	0 VAC
Supply voltage at AC, 60 Hz - max	0 VAC
Supply voltage at AC, 60 Hz - min	0 VAC
Supply voltage at DC - max	28.8 VDC
Supply voltage at DC - min	20.4 VDC
Heat dissipation details	Without local I/O
Signal range	19.2 - 30 V DC (Power supply of local inputs/outputs, note polarity)
Terminal capacity (flexible)	0.34 - 1.0 mm²
Interfaces	USB Host (built-in) USB 2.0 RS232 (built-in) Ethernet 100Base-TX/10Base-T (built-in) CANopen®/easyNet (built-in)
System accessory	Yes
Limit value type 1	High: > 15 V DC Low: < 5 V DC
Utilization factor	1 (Inductive load to EN 60947-5-1, Without external suppressor circuit, T0.95 = 1 ms, R = 48 Ω, L = 16 mH)
Potential isolation	Power supply of local inputs/outputs (24 V/0 V) against CPU voltage: yes CANopen®: yes Ethernet: no
Number of inputs (digital)	8
Voltage dips	10 ms
Terminal capacity (flexible with ferrule)	0.5 - 1.5 mm²
Terminal capacity (solid)	0.14 - 1.0 mm² 0.5 - 2.5 mm²
