Eaton Moeller® series E58 Thru-beam photoelectric sensor

Name: Eaton Moeller® series E58 Thru-beam photoelectric sensor
Brand: Eaton
SKU: 135571

رقم القطعة: 135571

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller® series E58 Thru-beam photoelectric sensor

المواصفات

Ambient operating temperature - max	70 °C
Ambient operating temperature - min	-20 °C
Functions	Detector (for combination with source) Protection against polarity reversal Thru-light beam Short-circuit protection
Product Name	Eaton Moeller® series E58 Thru-beam photoelectric sensor
Catalog Number	135571
Model Code	12100R6517
EAN	4015081323647
Product Length/Depth	158.75 mm
Product Height	50.8 mm
Product Width	133.35 mm
Product Weight	0.32 kg
Certifications	CSA File No.: 50513 UL Category Control No.: NRKH, NRKH7 UL 508 UL File No.: E117028 CSA-C22.2 No. 14 IEC/EN 60947-5-2 CE UL CSA CSA Class No.: 3211-07
Source URL	https://www.eaton.com/gb/en-gb/skuPage.135571.html
Features	Right-angled beam
Type	Optical sensors
Degree of protection	NEMA 1 IP67
Enclosure material	Plastic
Shock resistance	100 g, Mechanical, Shock duration 3 ms
Electric connection type	Cable
Product category	Comet Series
Connection type	4-wire 2 m connection cable
Enclosure type	Cylinder, screw-thread
Voltage type	DC
Cable sheath material	Polyurethane (PUR)
Operating mode	Switching principle: Adjustable bright/dark switching
Explosion safety category for dust	None
Explosion safety category for gas	None
Light type	Polarity free red light
Interface type	Other
LED indicator	Status indication of Switching state: Red LED
Switch function type	Other
Load current	Max. 250 mA (Ie, NPN, 120 > 50°C) Max. 100 mA (Ie, PNP)
Laser protection class	None
Optical surface material	Plastic
Output current (mA) - max	100 mA
Rated control supply voltage (Us) at DC - max	30 V
Rated control supply voltage (Us) at DC - min	10 V
Rated switching distance (Sn)	6000 mm
Sensor length	65 mm
Switching distance - max	6000 mm
Voltage rating - max	30 V
Safety type (IEC 61496-1)	1
Switching frequency	142 Hz
Sensing mode	Light-/dark switching
Switching output type	NPN
Sensor material	Insulated material
Response time	7 ms
Number of contact energized outputs with signalling function	0
Number of outputs (protected contact energized)	0
Number of outputs (protected semiconductor)	0
Number of outputs (semiconductor with signaling function)	0
Adjustment type	Manual adjustment
Wire size	0
Operation agent-safety class	Safety class 2
Device type	Receiver
Diameter sensor	18 mm
Operational current (Ib) in the switched state at 24 V DC	30 A
