Eaton Bussmann series high speed square body fuse

Eaton

Eaton Bussmann series high speed square body fuse

رقم القطعة: 170M2620

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Bussmann series high speed square body fuse

المواصفات

Product NameEaton Bussmann series high speed square body fuse
Catalog Number170M2620
Model CodeFUSE 350A 690V 00/80 AR UR
EAN5027590442299
Product Length/Depth233 mm
Product Height66 mm
Product Width140 mm
Product Weight233 g
CompliancesCE Marked RoHS Compliant
CertificationsUL Recognized IEC Rated
Source URLhttps://www.eaton.com/gb/en-gb/skuPage.170M2620.html
Amperage Rating350 A
Voltage rating690 V (IEC), 700 V (UL)
UPC051712254175
ClassClass aR
Clearing (I2T)91500 at 660 V
Watt losses60 W
Pre arc (I2T)13500
Interrupt rating200 kAIC
