Eaton Moeller series busbar

Name: Eaton Moeller series busbar
Brand: Eaton
SKU: 219573

رقم القطعة: 219573

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller series busbar

Functions	Busbar
Product Name	Eaton Moeller series busbar
Catalog Number	219573
Model Code	EVG-2PHAS/4MODUL/HI
EAN	9010238140202
Product Length/Depth	75.5 mm
Product Height	30.9 mm
Product Width	7.5 mm
Product Weight	0.02 kg
Compliances	RoHS conform
Source URL	https://www.eaton.com/gb/en-gb/skuPage.219573.html
Suitable for	Devices with auxiliary switch 2 devices
Used with	Busbar EVG
Features	Insulated
Type	BusbarEVG
Color	Other
Accessory/spare part type	Busbar for residual current circuit breakers Busbar for miniature circuit breaker Busbar for combined residual current/power circuit breaker
Electric connection type	Fork
Number of poles	Two-pole
Rated operational voltage (Ue) - max	500 V
Rated uninterrupted current (Iu)	63 A
Cross section	10 mm²
Rated conditional short-circuit current (Iq)	25 kA
Rated surge voltage	4 KV
Suitable for number of devices	7
Number of modular spacings	4
Number of phases	2
