Eaton Moeller series NZM operating element

Eaton

Eaton Moeller series NZM operating element

رقم القطعة: 266674

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller series NZM operating element

المواصفات

Special featuresExternal warning plate/designation label can be clipped on.For enhanced busbar tag shroud on the incomer side, please order IP2X protection against contact with a finger.Kit for use as a main switch
Product NameEaton Moeller series NZM operating element
Catalog Number266674
Model CodeNZM2-XSRM-R
EAN4015082666743
Product Length/Depth190 mm
Product Height220 mm
Product Width190 mm
Product Weight2.046 kg
CompliancesUL/CSA IEC RoHS conform
CertificationsCSA (Class No. 1437-01) UL listed CSA-C22.2 No. 5-09 UL (Category Control Number DIHS) CE marking CSA (File No. 22086) UL489 IEC60947 UL (File No. E140305) CSA certified
Source URLhttps://www.eaton.com/gb/en-gb/skuPage.266674.html
Suitable forEmergency stop Switch disconnector Power circuit breaker
Used withPN2(-4) N(S)2(-4) NZM2(-4)
FeaturesLockable Red-yellow for emergency switching off For direct mounting of circuit-breaker and handle in the side wall of the control cabinet
TypeAccessoryMain switch assembly kit for side panel mounting
Fitted with:Black and yellow lightning symbol Extension shaft Door coupling rotary handle External warning plate/marking plate in German/English Special short extension shaft Mounting brackets Padlock
FrameNZM2
