Eaton Moeller® series DILA Control relay

Eaton

Eaton Moeller® series DILA Control relay

رقم القطعة: 276495

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller® series DILA Control relay

المواصفات

Ambient operating temperature (enclosed) - max40 °C
Ambient operating temperature (enclosed) - min25 °C
Ambient operating temperature - max60 °C
Ambient operating temperature - min-25 °C
Ambient storage temperature - max80 °C
Ambient storage temperature - min40 °C
Climatic proofingDamp heat, constant, to IEC 60068-2-78 Damp heat, cyclic, to IEC 60068-2-30
Product NameEaton Moeller® series DILA Control relay
Catalog Number276495
Model CodeDILAC-22(24V50HZ)
EAN4015082764951
Product Length/Depth75 mm
Product Height68 mm
Product Width45 mm
Product Weight0.225 kg
CompliancesCE Marked
CertificationsEN 60947-4-1 UL 508 CSA Std. C22.2 No. 14-05 IEC 60947-4-1 VDE CSA Class No.: 3211-03 CSA File No.: 012528 IEC/EN 60947 CSA-C22.2 No. 14-05 VDE 0660 CSA IEC/EN 60947-4-1 CE UL Category Control No.: NKCR EN 60947-5-1 UL UL File No.: E29184
Source URLhttps://www.eaton.com/gb/en-gb/skuPage.276495.html
Catalog NotesThis item can only be ordered until December 31, 2023 with a maximum delivery date of May 31, 2024.
