Eaton Moeller series Luxury finish range (COPA) - Wiring devices

Eaton

Eaton Moeller series Luxury finish range (COPA) - Wiring devices

رقم القطعة: C421NWH

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller series Luxury finish range (COPA) - Wiring devices

المواصفات

Special featuresZinc Coated Steel with clear Passivation
Product NameEaton Moeller series Luxury finish range (COPA) - Wiring devices
Catalog NumberC421NWH
Model CodeC421NWH
EAN5010826127268
Product Length/Depth45 mm
Product Height146 mm
Product Width86 mm
Product Weight0.164 kg
CompliancesRoHS conform
CertificationsIEC 60669-1 BS EN 60669-1
Source URLhttps://www.eaton.com/gb/en-gb/skuPage.C421NWH.html
FeaturesHalogen free Push button switch
TypeCopa Switches
Surface finishingMatt
Degree of protectionIP20 IP3X
Surface protectionUntreated
Built-in depth25 mm
ColorWhite
Mounting methodFlush mounted (plaster)
MaterialUrea Plastic
Material qualityDuroplast
Amperage Rating50 A
Voltage rating250 V AC
Connection typeScrew terminal
Nominal voltage - max240 V
IlluminationYes
RAL-number (Akin)0
Fastening typeScrew mounting
Built-in installation box depth - min47 mm
Switch typeDouble pole
Wiring system2-pole switch
Contact materialSilver Nickel
Head styleCombination head
Assembly arrangementBasic element with full cover plate
Base colorGray
Base materialThermoplastic
Terminal materialBrass
Number of modules (module system)0
Number of rockers1
Number of gangs1
Fixing centers120.6 mm
Front plate color/finishingWhite
Front plate depth6.5 mm
Front plate materialThermoplastic
Front plate/module dimensions148 mm x 87 mm
Method of operationRocker/button
Function lightingIlluminated (on)
Rocker colorWhite
Terminal capacity (LN and E)4 mm² (3x) or 6 mm² (2x) or 10 mm² (1x)
Label space/information surfaceNo
Lighting typeNot included
Recommended back box depth - min47 mm
Switching current of fluorescent lamps50 Ampere AC/DC
COPA interiorWhite insert
