Eaton Moeller series xPole UK - EM.H MCB

رقم القطعة: EMBH125N

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton Moeller series xPole UK - EM.H MCB

المواصفات

Ambient operating temperature - max75 °C
Ambient operating temperature - min-25 °C
Product NameEaton Moeller series xPole UK - EM.H MCB
Catalog NumberEMBH125N
Model CodeEMBH125N
EAN5019586125088
Product Length/Depth85 mm
Product Height73 mm
Product Width35 mm
Product Weight0.24 kg
CompliancesRoHS conform
Source URLhttps://www.eaton.com/gb/en-gb/skuPage.EMBH125N.html
Used withEM Miniature circuit breaker
FeaturesConcurrently switching N-neutral Additional equipment possible
TypeEMMiniature circuit breaker
Degree of protectionIP20
Built-in depth70.5 mm
Width in number of modular spacings2
Number of polesSingle-pole + N
Amperage Rating25 A
Rated operational voltage (Ue) - max230 V
Pollution degree2
Rated insulation voltage (Ui)440 V
Overvoltage categoryIII
Rated impulse withstand voltage (Uimp)4 kV
Voltage typeAC
Connectable conductor cross section (multi-wired) - max25 mm²
Connectable conductor cross section (multi-wired) - min1 mm²
Connectable conductor cross section (solid-core) - max25 mm²
Connectable conductor cross section (solid-core) - min1 mm²
ApplicationSwitchgear for residential and commercial applications
Current limiting class3
Frequency rating - max60 Hz
Frequency rating - min50 Hz
Tripping characteristicB
Number of poles (protected)1
Number of poles (total)2
Release characteristicB
Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 230 V15 kA
Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 400 V15 kA
Rated switching capacity (IEC/EN 60947-2)15 kA
Rated short-circuit breaking capacity (IEC/EN 60898-1) - Icn at 230 V10 kA
Rated short-circuit breaking capacity (IEC/EN 60898-1)- Icn at 400 V10 kA
Rated switching capacity (IEC/EN 60898-1)10 kA
