Eaton PSG power supply unit

Eaton

Eaton PSG power supply unit

رقم القطعة: EP-401399

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eaton PSG power supply unit

المواصفات

Product NameEaton PSG power supply unit
Catalog NumberEP-401399
Model CodePSG240F24SMB
Product Length/Depth124 mm
Product Height125.3 mm
Product Width50 mm
Product Weight0.84 kg
CertificationsIEC 62368-1 EN 61010-1 EN 61010-2-201: 2018 EN 55032 EN 61000-3-2 EN 61000-3-3 CISPR 35/EN 55035 EN 61000-4-12: 2017 EN 61000-6-1: 2007 EN 61000-6-3 IEC/EN 61204-3 EN IEC 63000 RoHS conform REACH TSCA P65 SELV (EN 60950) CE: In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2006/95/EC BS EN 62368-1 UL 62368-1 IEC/EN 61000-4-2 IEC/EN 61000-4-3 IEC 61000-4-4 IEC 61000-4-5 IEC 61000-4-6 IEC 61000-4-8: 2010 EN 61000-4-11 CSA C22.2 No. 61010-2-201 UL 61010-2-201
Source URLhttps://www.eaton.com/gb/en-gb/skuPage.EP-401399.html
Catalog NotesPower supply can operate at DC input voltage, please connect +pole to L, -pole to N and PE terminal to an earth wire or to the machine ground.Back-up fuse: 4 A, type B/C
Shock resistance50 g, Mechanical, according to IEC/EN 60068-2-27, Half-sinusoidal shock 11 ms, 3 Impacts
Vibration resistance10 - 500 Hz at 30 m/s² (3 G max ) for 60 min. in X-axis, Y-axis, Z-axis directions, (IEC/EN 60068-2-6)
UPC786689860738
