AUX-C 3Q+1SY 250Vac/dc XT2..XT6 F/P
رقم القطعة: 1SDA066434R1
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
ملحق AUX-C 3Q+1SY 250Vac/dc XT2..XT6 F/P
المواصفات
| Extended Product Type | AUX-C 3Q+1SY 250Vac/dc XT2..XT6 F/P |
|---|---|
| Product ID | 1SDA066434R1 |
| EAN | 8015644003449 |
| Catalog Description | AUX-C 3Q+1SY 250Vac/dc XT2..XT6 F/P |
| Long Description | 3 changeover contact open-closed + 1 changeover for tripped indication V<250V AC-DC wired on c.breaker fixed-plug-in XT2...XT6 |
| Display Name | AUX-C 3Q+1SY 250Vac/dc XT2..XT6 F/P |
| Country of Origin | India |
| Made To Order | No |
| Warranty Return | Product under warranty must be returned |
| Product Sales Status | Active |
| Quote Only | No |
| Stocked At Warehouses | AETAD009EXPU |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| Instructions and Manuals | 1SDH000719R0615 |
| Product Net Weight | 0.153 kg |
| Standards | IEC60947-2 |
| Product Name | Accessory |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Declaration of Conformity - CE | Refer to the EU Declaration of the relative Circuit Breaker |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 110 mm |
| Package Level 1 Depth / Length | 140 mm |
| Package Level 1 Height | 60 mm |
| Package Level 1 Gross Weight | 0.161 kg |
| Package Level 1 EAN | 8015644003449 |
| Object Classification Code | Q |
| ETIM 9 | EC000041 - Auxiliary contact block |
| eClass | V11.1 : 27371302 |
| UNSPSC | 39121522 |
| IDEA Granular Category Code (IGCC) | 4743 >> Auxiliary contact block |
| E-Number (Finland) | 3638679 |
| E-Number (Norway) | 4384918 |
| E-Number (Sweden) | 3182065 |
| Source URL | https://new.abb.com/products/1SDA066434R1/aux-c-3q1sy-250vac-dc-xt2-xt6-f-p |
| ABB Taxonomy Path | Low Voltage Products and Systems > Circuit Breakers > Moulded Case Circuit Breakers > Accessories for Tmax XT |
| ABB Classification IDs | 9AAC910006, 9AAC167302 |
| Suitable For | XT2 |
| Suitable for Product Class | SACE Tmax XT |
| ETIM 10 | EC000041 - Auxiliary contact block |
| Lead Time | 0 day |
| Country of Origin (CountryOfOrigin_PUCNILX002) | China |
| Lead Time (LeadTime_PUCNILX002) | 17 day |
| Made To Order (MadeToOrder_PUCNILX002) | No |
| Warranty Return (NoWarrantyReturn_PUCNILX002) | Product under warranty must be returned |
| Product Sales Status (ProductSalesStatus_PUCNILX002) | Inactive |
| Quote Only (QuoteOnly_PUCNILX002) | No |
| Country of Origin (CountryOfOrigin_PUINABB015) | India |
| Made To Order (MadeToOrder_PUINABB015) | No |
| Warranty Return (NoWarrantyReturn_PUINABB015) | Product under warranty must be returned |
| Product Sales Status (ProductSalesStatus_PUINABB015) | Active |
| Quote Only (QuoteOnly_PUINABB015) | No |
| Stocked At Warehouses (StockedAtWarehouses_PUINABB015) | INABB015EXPU |
| Country of Origin (CountryOfOrigin_PUBRABB008) | India |
| Lead Time (LeadTime_PUBRABB008) | 0 day |
| Made To Order (MadeToOrder_PUBRABB008) | No |
| Warranty Return (NoWarrantyReturn_PUBRABB008) | Product under warranty must be returned |
| Product Sales Status (ProductSalesStatus_PUBRABB008) | Active |
| Quote Only (QuoteOnly_PUBRABB008) | No |
| Stocked At Warehouses (StockedAtWarehouses_PUBRABB008) | BRABB008EXPU |
| Country of Origin (CountryOfOrigin_PUCHSEC006) | India |
| Lead Time (LeadTime_PUCHSEC006) | 0 day |
| Made To Order (MadeToOrder_PUCHSEC006) | No |
| Warranty Return (NoWarrantyReturn_PUCHSEC006) | Product under warranty must be returned |
| Product Sales Status (ProductSalesStatus_PUCHSEC006) | Active |
| Quote Only (QuoteOnly_PUCHSEC006) | No |
| Stocked At Warehouses (StockedAtWarehouses_PUCHSEC006) | CHSEC006EXPU |
| Country of Origin (CountryOfOrigin_PUINABB003) | India |
| Made To Order (MadeToOrder_PUINABB003) | No |
| Product Sales Status (ProductSalesStatus_PUINABB003) | Active |
| Quote Only (QuoteOnly_PUINABB003) | No |
| Stocked At Warehouses (StockedAtWarehouses_PUINABB003) | INABB003EXPU |
| Warranty Return (NoWarrantyReturn_PUINABB003) | Product under warranty must be returned |
| Environmental Information | 9AKK108467A6707 |
| Product Main Type | Accessories for Tmax XT |
| Order Multiple | 1 piece |
| Product Type | Accessory |
| Order Code US and Canada | KXTDAXC3QSYFP |
| Configuration Type | Loose or configurable |
| Number of Auxiliary Contacts CO (SPDT) | 4 |
