INS-S/H
رقم القطعة: 2CCG001213R0001
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
وحدة مراقبة وقياس INS-S/H
المواصفات
| Extended Product Type | INS-S/H |
|---|---|
| Product ID | 2CCG001213R0001 |
| EAN | 7612271516826 |
| Catalog Description | SMART SIGNALLING DEVICE SCU100&SCU200 |
| Long Description | INS-S/H InSite pro M compact - Smart signal/auxiliary contact |
| Display Name | INS-S/H |
| Data Sheet, Technical Information | 9AKK108467A9377 |
| Product Net Width | 8.8 mm |
| Product Net Depth / Length | 64.9 mm |
| Product Net Height | 87 mm |
| Product Net Weight | 30 g |
| Standards | EN 61010-1 / IEC 61010-1 |
| Power Loss | Total 0.1 W |
| Degree of Protection | IP20 |
| Ambient Air Temperature | Operation -25 ... 60 °C |
| Maximum Operating Altitude Permissible | 2000 m |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| REACH Declaration | 9AKK108467A9482 |
| RoHS Declaration | 9AKK108468A4471 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| EcoSolutions Profile | 9AKK108472A1199 |
| End Of Life Disassembling Instructions | 9AKK108470A1391 |
| Environmental Product Declaration - EPD | 9AKK108470A0919 |
| Improved Energy Efficiency for Customers | Process Efficiency - Product improves/optimizes process |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 46.25 % |
| Declaration of Conformity - CE | 9AKK108468A4471 |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 316 g |
| ETIM 9 | EC002758 - Energy management controller |
| UNSPSC | 41111928 |
| E-Number (Finland) | 6719031 |
| E-Number (Norway) | 8002543 |
| Source URL | https://new.abb.com/products/2CCG001213R0001/ins-s-h |
| ABB Taxonomy Path | Low Voltage Products and Systems > Modular DIN Rail Products > InSite Pro M Compact |
| ABB Classification IDs | 9AAC910006, 9AAF604576, 9AAF626769 |
| Rated Operational Current AC-15 (I<sub>e</sub>) | 0.7 A |
| ETIM 10 | EC002758 - Energy management controller |
| Technical Information | Smart signalling device that can communicate the status of corresponding breakers over InSite bus(Flat cable) to SCU100 & SCU200 |
| Mounting Type | DIN-Rail |
| Extended Product Lifetime | Lifetime extension of customer’s assets is made possible thanks to offering and the supporting services |
| EU Data Act Compliance Declaration | 9AKK108471A5056 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| RoHS Date | 20241030 |
| Sustainable Material Content in Packaging (wt. %) | Recycled Cardboard - 82.06 % |
| Product Compatibility | SCU100 & SCU200 |
| Communication Interface | InSite bus(Flat cable) |
| Power Consumption (@P<sub><span style="font-size:x-small;">cons</span></sub>) | 0 kW |
| Declaration | CE |
| Offered with Takeback Services | Take Back for Recycling |
