EF45-45

ABB

EF45-45

رقم القطعة: 1SAX221001R1102

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

ريليه إلكتروني للحماية من التحميل الزائد EF45-45، ثلاثي الأقطاب

المواصفات

Extended Product TypeEF45-45
Product ID1SAX221001R1102
EAN4013614403972
Catalog DescriptionEF45-45 Electronic Overload Relay 15 ... 45 A
Long DescriptionThe EF45-45 is an self-supplied electronic overload relay, which means no extra external supply is needed. It offers reliable and fast protection for motors in the event of overload or phase failure. Easy to use like a thermal overload relay and compatible with standard motor applications, the electronic overload relay is convincing, above all, due to its wide setting range, high accuracy, high operational temperature range and the possibility to select a trip class (10E, 20E, 30E). Further features are the temperature compensation, trip contact (NC), signal contact (NO), automatic- or manual reset selectable, trip-free mechanism, STOP- and Test function and a trip indication. The overload relays are connected directly to the contactors. Single mounting kits are available as accessory. The EF19 and EF45 have ATEX and IECEx certification 1) 1) ATEX is valid for products produced from week 42, 2014. IECEx is valid for products produced from week 15, 2017.
Display NameEF45-45
Country of OriginChina
Made To OrderNo
Warranty ReturnProduct under warranty must be returned
Product Sales StatusActive
Quote OnlyNo
Stocked At WarehousesAETAD009EXPU
Minimum Order Quantity1 piece
Customs Tariff Number85364900
Data Sheet, Technical Information2CDC107025D0201
Instructions and Manuals2CDC107024M6803
CAD Dimensional Drawing2CDC001079B0201
Product Net Width45 mm
Product Net Depth / Length86 mm
Product Net Height104.7 mm
Product Net Weight0.362 kg
Number of Auxiliary Contacts NO1
Number of Auxiliary Contacts NC1
Number of Poles3P
StandardsIEC/EN 60947-1
Rated Operational VoltageAuxiliary Circuit 600 V AC/DC
Rated Frequency (f)Auxiliary Circuit 50 Hz
Rated Insulation Voltage (U<sub>i</sub>)690 V
Rated Impulse Withstand Voltage (U<sub>imp</sub>)Auxiliary Circuit 6 kV
Power Lossat Rated Operating Conditions per Pole 0.059 ... 0.527 W
Connecting Capacity Main CircuitFlexible with Ferrule 1/2x 2.5 ... 10 mm²
Wire Stripping LengthAuxiliary Circuit 9 mm
Degree of ProtectionIP20
Recommended Screw DriverAuxiliary Circuit Pozidriv 2
Tightening TorqueAuxiliary Circuit 0.8 ... 1.2 N·m
Maximum Operating Voltage UL/CSAMain Circuit 600 V AC
Connecting Capacity Main Circuit UL/CSAFlexible 1/2x 14-6 AWG
Tightening Torque UL/CSAAuxiliary Circuit 7 ... 1 in·lb
Ambient Air TemperatureOperation -25 ... +70 °C
Maximum Operating Altitude Permissible2000 m
Resistance to Shock acc. to IEC 60068-2-2711 ms Pulse 25g
Pollution Degree3
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration2CMT2021-006202
RoHS Declaration2CMT2021-006277
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006525
WEEE B2C / B2BBusiness To Business
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
ABB EcoSolutionsYes
ABB Site Meeting Group Waste To Landfill TargetUL 2799 Zero Waste To Landfill Validation available
EcoSolutions Profile1SFC100125C0415
End Of Life Disassembling Instructions1SAC200380H0001
Environmental Product Declaration - EPD1SAC200356H0001
Improved Energy Efficiency for CustomersProduct Efficiency - Product considered more energy-efficient compared to similar product on market or older products from the same line
Recyclability Rate of the Product acc. to EN45555Design for Closing Resource Loops - Standard EN45555 - 89.2 %
ABS Certificate1SAA941002-0102
CB Certificate1SAA964003-2002
CCC Certificate2024010304654684
Declaration of Conformity - CE1SAD101100-3601
Declaration of Conformity - UKCA1SAD201100-3601
DNV Certificate1SAA941003-0302
RINA CertificateRINA_ELE376813CS
UL CertificateE48139-19990512
Package Level 1 Unitsbox 1 piece
Package Level 1 Width111 mm
Package Level 1 Depth / Length93 mm
Package Level 1 Height51.5 mm
Package Level 1 Gross Weight0.398 kg
Package Level 1 EAN4013614403972
Object Classification CodeF
ETIM 9EC001080 - Electronic overload relay
eClassV11.0 : 27371502
UNSPSC39122330
IDEA Granular Category Code (IGCC)5365 >> Electronic overload relay
E-Number (Finland)3706157
E-Number (Norway)4116836
E-Number (Sweden)3224186
Source URLhttps://new.abb.com/products/1SAX221001R1102/ef45-45
ABB Taxonomy PathLow Voltage Products and Systems > Control Products > Contactors > Electronic Overload Relays
ABB Classification IDs9AAC910006, 9AAC100110, 9AAC166911
Conventional Free-air Thermal Current (I<sub>th</sub>)Auxiliary Circuit NC 6 A
Rated Operational Current AC-15 (I<sub>e</sub>)(240 V) NC 3 A
Rated Operational Current DC-13 (I<sub>e</sub>)(125 V) NC 0.55 A
Connecting Capacity Auxiliary CircuitFlexible with Ferrule 1/2x 0.75 ... 2.5 mm²
Suitable ForAF26
Connecting Capacity Auxiliary Circuit UL/CSAFlexible 1/2x 18-10 AWG
Contact Rating UL/CSA(NC:) B600
Resistance to Vibrations5g 3 ... 150 Hz
BV Certificate1SAA941002-0201
CQC CertificateCQC2006010309192161
Declaration of Conformity - CCC2020980309000293
ETIM 10EC001080 - Electronic overload relay
Lead Time0 day
Country of Origin (CountryOfOrigin_PUINABB015)India
Made To Order (MadeToOrder_PUINABB015)No
Warranty Return (NoWarrantyReturn_PUINABB015)Product under warranty must be returned
Product Sales Status (ProductSalesStatus_PUINABB015)Active
Quote Only (QuoteOnly_PUINABB015)No
Stocked At Warehouses (StockedAtWarehouses_PUINABB015)INABB015EXPU
Mounting Position1 ... 6
EAC Certificate1SAA941003-2701
LR Certificate1SAA941002-0501
Country of Origin (CountryOfOrigin_PUBRABB008)China
Lead Time (LeadTime_PUBRABB008)0 day
Made To Order (MadeToOrder_PUBRABB008)No
Warranty Return (NoWarrantyReturn_PUBRABB008)Product under warranty must be returned
Product Sales Status (ProductSalesStatus_PUBRABB008)Active
Quote Only (QuoteOnly_PUBRABB008)No
Stocked At Warehouses (StockedAtWarehouses_PUBRABB008)BRABB008EXPU
Country of Origin (CountryOfOrigin_PUCHSEC006)China
Lead Time (LeadTime_PUCHSEC006)0 day
Made To Order (MadeToOrder_PUCHSEC006)No
Warranty Return (NoWarrantyReturn_PUCHSEC006)Product under warranty must be returned
Product Sales Status (ProductSalesStatus_PUCHSEC006)Active
Quote Only (QuoteOnly_PUCHSEC006)No
Stocked At Warehouses (StockedAtWarehouses_PUCHSEC006)CHSEC006EXPU
Country of Origin (CountryOfOrigin_PUCZABB006)China
Lead Time (LeadTime_PUCZABB006)28 day
Made To Order (MadeToOrder_PUCZABB006)No
Product Sales Status (ProductSalesStatus_PUCZABB006)Active
Quote Only (QuoteOnly_PUCZABB006)No
Stocked At Warehouses (StockedAtWarehouses_PUCZABB006)CZABB006EXPU
Warranty Return (NoWarrantyReturn_PUCZABB006)Product under warranty must be returned
Dimension Diagram1SAX200403F0001
Instructions and Manuals (Part 2)1SAC200017M0002
Time-Current Characteristic Curve1SAX100509F0002
Setting Range15 ... 45 A
Rated Operational Current (I<sub>e</sub>)45 A
Ambient Air Temperature CompensationYes
RMRS Certificate1SAA964000-0703
Ex Operating Instructions2CDC107043M6801
ATEX Certificate1SAA941004-3901
IECEx Certificate1SAA941000-4001
Number of Protected Poles3
Environmental Information1SAC200097H0001
CCS Certificate1SAA941001-0901
