N2155.5 BL
رقم القطعة: 2CLA215550N1101
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
وحدة حماية لخطوط البيانات والاتصالات والهوائي N2155.5 BL
المواصفات
| Extended Product Type | N2155.5 BL |
|---|---|
| Product ID | 2CLA215550N1101 |
| EAN | 8427238142241 |
| Catalog Description | Insert/cover DSub15Pole 1 gang White - Zenit |
| Long Description | Color: White. Front: 1x VGA connector (DE-15 connector) Rear: screw terminals (15 wires) Size: 1 module. |
| Display Name | N2155.5 BL |
| Data Sheet, Technical Information | 9AKK10103A5108 |
| Instructions and Manuals | 2CLX200009N1001 |
| Product Net Width | 22 mm |
| Product Net Depth / Length | 31 mm |
| Product Net Height | 44 mm |
| Product Net Weight | 41 g |
| Degree of Protection | IP20 |
| Ambient Air Temperature | Operation -5 ... +35 °C |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| REACH Declaration | 2CLC00000000884 |
| RoHS Declaration | 2CLC00000005636 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Consumer |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Declaration of Conformity - CE | 9AKK106930A1758 |
| ETIM 9 | EC000018 - Insert/cover for communication technology |
| Source URL | https://new.abb.com/products/2CLA215550N1101/n2155-5-bl |
| ABB Taxonomy Path | Low Voltage Products and Systems > Wiring Accessories - Light Switch Ranges > Cover Plates and Control Elements > Data / Telecommunication / Antenna |
| ABB Classification IDs | 9AAC910006, 9AAF628011, 9AAF628561 |
| SCIP | 5c94c12a-b5d9-4031-b7ed-8b483a6f356d Spain |
| ETIM 10 | EC000018 - Insert/cover for communication technology |
| Color | White |
| Mounting Type | Flush-mounted |
| EU Data Act Applicability and Compliance | Not Applicable |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20251231 |
| RAL Number | RAL 9010 - Pure White |
| Number of Modules | 1 |
| Design Range | Zenit |
| Outlet Orientation | Straight |
| Material | Plastic;Thermoplastic |
| Type of Fastening | Engage (Snap) |
| Surface Finishing | Untreated;Glossy |
| Application | DSub15Pole |
| Number of Batteries | 0 |
| Replaced Product ID (OLD) | 2CLA215550N1102 |
| Type of Indicator | Without indication field |
