OVR SLTN
رقم القطعة: 7TCA085400R0323
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
جهاز حماية من الجهد العابر لخطوط الاتصالات والحاسب OVR SLTN
المواصفات
| Extended Product Type | OVR SLTN |
|---|---|
| Product ID | 7TCA085400R0323 |
| EAN | 5415022374452 |
| Catalog Description | OVR SLTN Surge Protective Device |
| Long Description | OVR SLTN SLIM LINE DATA SPD FOR TWISTED PAIR TELEPHONE LINES |
| Display Name | OVR SLTN |
| Data Sheet, Technical Information | 9AKK106713A8157 |
| Instructions and Manuals | 9AKK106713A8726 |
| Product Net Width | 106.5 mm |
| Product Net Depth / Length | 7 mm |
| Product Net Height | 104.6 mm |
| Product Net Weight | 0.08 kg |
| Standards | IEC 61643-21 |
| Rated Frequency (f) | 20 MHz |
| Wire Stripping Length | 9.5 mm |
| Ambient Air Temperature | Operation -40 ... +80 °C |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108472A2584 |
| REACH Declaration | 9AKK108466A5047 |
| RoHS Declaration | 9AKK108466A5046 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Declaration of Conformity - CE | 7TKK001511 |
| Package Level 1 Units | 1 piece |
| ETIM 9 | EC000943 - Surge protection device for data networks/MCR-technology |
| Source URL | https://new.abb.com/products/7TCA085400R0323/ovr-sltn |
| ABB Taxonomy Path | Low Voltage Products and Systems > Modular DIN Rail Products > Surge Protective Devices SPDs > ABB OVR telecoms & computer line protection |
| ABB Classification IDs | 9AAC910006, 9AAF618149, 9AAC187686, 9AAF618123, 9AAC187663, 9AAF618151, 9AAC187838, 9AAF618125, 9AAC187667 |
| Suitable For | To protect systems against transient overvoltages or surges from lightning and electrical switching events |
| ETIM 10 | EC000943 - Surge protection device for data networks/MCR-technology |
| Number of Protected Poles | 3 |
| Rated Current (I<sub>n</sub>) | 750 mA |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20250121 |
| Connection Type | Screw Clamp |
| Voltage Protection Level ( Up) | 298 V |
| Maximum Continuous Operating Voltage (U<sub>c</sub>) | 296 V |
| Discharge Current | I (max, 8 / 20 µs) 10 kA |
| Serial Resistance | 1 Ω |
