AF1650-30-11-70
رقم القطعة: 1SFL677001R7011
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
كونتاكتور AF1650-30-11-70، ثلاثي الأقطاب
المواصفات
| Extended Product Type | AF1650-30-11-70 |
|---|---|
| Product ID | 1SFL677001R7011 |
| EAN | 7320500249703 |
| Catalog Description | AF1650-30-11 100-250V 50/60Hz / 100-250V DC Contactor |
| Long Description | The AF1650-30-11-70 is a 3 pole - 1000 V IEC or 1000 V UL contactor pre-mounted auxiliary contacts and and Main Circuit Bars, controlling motors up to 560 kW / 400 V AC (AC-3) or 900 hp / 480 V UL and switching power circuits up to 1650 A (AC-1) or 1650 A UL general use. Thanks to the AF technology, the contactor has a wide control voltage range (100-250 V 50/60 Hz and DC), managing large control voltage variations, reducing panel energy consumptions and ensuring distinct operations in unstable networks. Furthermore, surge protection is built-in, offering a compact solution. AF contactors have a block type design, can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories. |
| Display Name | AF1650-30-11-70 |
| Country of Origin | Sweden |
| Made To Order | No |
| Warranty Return | Product under warranty must be returned |
| Product Sales Status | Active |
| Quote Only | No |
| Stocked At Warehouses | BRAPR001EXPU |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85364900 |
| EPLAN Data | 9AAC200759_EPLAN |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Instructions and Manuals | 1SFC101002M5501 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Product Net Width | 438 mm |
| Product Net Depth / Length | 244 mm |
| Product Net Height | 392 mm |
| Product Net Weight | 33 kg |
| Number of Main Contacts NO | 3 |
| Number of Main Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 1 |
| Number of Auxiliary Contacts NC | 1 |
| Number of Poles | 3P |
| Rated Operational Voltage | Main Circuit 1000 V |
| Rated Frequency (f) | Main Circuit 50 / 60 Hz |
| Rated Operational Current AC-1 (I<sub>e</sub>) | (1000 V) 40 °C 1650 A |
| Rated Operational Current AC-3 (I<sub>e</sub>) | (415 V) 55 °C 1060 A |
| Rated Operational Power AC-3 (P<sub>e</sub>) | (415 V) 630 kW |
| Rated Breaking Capacity AC-3 | 8 x Ie AC-3 |
| Rated Making Capacity AC-3 | 10 x Ie AC-3 |
| Rated Short-time Withstand Current Low Voltage (I<sub>cw</sub>) | at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 10000 A |
| Rated Insulation Voltage (U<sub>i</sub>) | acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 1000 V |
| Rated Impulse Withstand Voltage (U<sub>imp</sub>) | Main Circuit 8 kV |
| Maximum Electrical Switching Frequency | (AC-1) 60 cycles per hour |
| Mechanical Durability | 0.5 million |
| Coil Operating Limits | (acc. to IEC 60947-4-1) 0.85 x Uc Min. ... 1.1 x Uc Max. (at θ ≤ 70 °C) |
| Rated Control Circuit Voltage (U<sub>c</sub>) | 50 Hz 100 ... 250 V |
| Coil Consumption | Holding at Max. Rated Control Circuit Voltage 50 Hz 75.7 V·A |
| Power Loss | at Rated Operating Conditions per Pole 80 W |
| Connecting Capacity Main Circuit | Bar 100 mm² |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20 |
| Recommended Screw Driver | Main Circuit M12 |
| Tightening Torque | Cable Lug 45 N·m |
| Terminal Type | Main Circuit: Bars |
| Product Name | Block Contactor |
| Maximum Operating Voltage UL/CSA | Main Circuit 1000 V |
| General Use Rating UL/CSA | (1000 V AC) 1650 A |
| Horsepower Rating UL/CSA | (220 ... 240 V AC) Three Phase 450 hp |
| Full Load Amps Motor Use | (440 ... 480 V AC) Three Phase 1030 A |
| Ambient Air Temperature | Close to Contactor Fitted with Thermal O/L Relay (0.85 ... 1.1 Uc) -25 ... 50 °C |
| Maximum Operating Altitude Permissible | Without Derating 3000 m |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| EcoSolutions Profile | 1SFC100125C0366 |
| End Of Life Disassembling Instructions | 1SFC100112M0005 |
| Environmental Product Declaration - EPD | 1SFC100110D0201 |
| Improved Energy Efficiency for Customers | Product Efficiency - Product considered more energy-efficient compared to similar product on market or older products from the same line |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 71.3 % |
| ABS Certificate | 15-LD1408622-PDA |
| CB Certificate | SEMKO_SE-74013 |
| Declaration of Conformity - CE | 2CMT2019-005796 |
| Declaration of Conformity - UKCA | 2CMT2020-006118 |
| DNV Certificate | TAE00001W1 |
| RINA Certificate | ELE060313XG_002 |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 555 mm |
| Package Level 1 Depth / Length | 365 mm |
| Package Level 1 Height | 500 mm |
| Package Level 1 Gross Weight | 35 kg |
| Package Level 1 EAN | 7320500249703 |
| Object Classification Code | Q |
| ETIM 7 | EC000066 - Power contactor, AC switching |
| ETIM 8 | EC000066 - Power contactor, AC switching |
| ETIM 9 | EC000066 - Power contactor, AC switching |
| eClass | V11.0 : 27371003 |
| UNSPSC | 39121529 |
| IDEA Granular Category Code (IGCC) | 4758 >> Iec Contactors |
| E-Number (Finland) | 3709258 |
| E-Number (Norway) | 4115390 |
| E-Number (Sweden) | 4115390 |
| Source URL | https://new.abb.com/products/1SFL677001R7011/af1650-30-11-70 |
| ABB Taxonomy Path | Low Voltage Products and Systems > Control Products > Contactors > Block Contactors > AF Contactors > AF1650 |
| ABB Classification IDs | 9AAC100211, 9AAC910006, 9AAC113410, 9AAC100109, 9AAC186707, 9AAC184308, 9AAC200759 |
| Conventional Free-air Thermal Current (I<sub>th</sub>) | acc. to IEC 60947-4-1, Open Contactors Θ = 40 °C 1650 A |
