Contactor assembly for star-delta (wye-delta) start AC-3, 75 kW/400 V 230 V AC, 50/60 Hz Size S3, sc
رقم القطعة: 3RA2445-8XF32-1AL2
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Contactor assembly for star-delta (wye-delta) start AC-3, 75 kW/400 V 230 V AC, 50/60 Hz Size S3, screw terminal electrical and mechanical interlock 3 NO+3 NC
المواصفات
| MLFB | 3RA2445-8XF32-1AL2 |
|---|---|
| EAN | 4047621031217 |
| Product Family | SIRIUS 3RA24 contactor assemblies for star-delta (wye-delta) starting, up to 90 kW |
| Catalog Node Id | 10046388 |
| Overview Node Id | 10007509 |
| Product Group | 5339 |
| Group Classification Key | R711 |
| Product Class | Straightforward, can be reused over the short term |
| Material Short Text | STAR-DELTA CONT. ASSY., AC3:75KW |
| Classification eClass | 27-37-10-09 (9.1); 27-37-10-09 (9); 27-37-10-09 (8); 27-37-10-09 (7.1); 27-37-10-09 (6); 27-37-10-09 (16); 27-37-10-09 (14); 27-37-10-09 (12) |
| Classification ETIM | EC000010 (9); EC000010 (8); EC000010 (7); EC000010 (10) |
| Net Weight | 5,516 Kg |
| Package Dimensions | 326 x 249 x 262 MM |
| Standard Package Quantity | 1 Piece |
| Minimum Order Quantity | 1 |
| Delivery Time | 30 Day/Days |
| Country Of Origin | Germany |
| Returnable | Yes |
| Commodity Code | 85364900 |
| Export Control | AL : N / ECCN : N_CNDU |
| WEEE2 Category | 5 |
| RoHS Conformity | Since: 01.03.17 |
| Lifecycle Milestone | P.M300 |
| Phased Out Since | 0001-01-01T00:00:00 |
| Available In Catalog | Yes |
| Saleable | Yes |
| Description DE | Contactor assembly for star-delta (wye-delta) start AC-3, 75 kW/400 V 230 V AC, 50/60 Hz Size S3, screw terminal electrical and mechanical interlock 3 NO+3 NC |
| Description FR | Contactor assembly for star-delta (wye-delta) start AC-3, 75 kW/400 V 230 V AC, 50/60 Hz Size S3, screw terminal electrical and mechanical interlock 3 NO+3 NC |
| Description ES | Contactor assembly for star-delta (wye-delta) start AC-3, 75 kW/400 V 230 V AC, 50/60 Hz Size S3, screw terminal electrical and mechanical interlock 3 NO+3 NC |
| Datasheet URL | https://mall.industry.siemens.com/teddatasheet/?format=PDF&mlfbs=3RA2445-8XF32-1AL2&language=en&caller=SiePortal |
| Classification IDEA | 4755 (4) |
| Classification UNSPSC | 39-12-15-29 (15) |
