Salvavita thermal magnetic circuit breaker with earth leakage protection - 1P+N 10A
رقم القطعة: BT-A5250S
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Salvavita thermal magnetic circuit breaker with earth leakage protection - 1P+N 10A
المواصفات
| Built-in depth | 47 mm |
|---|---|
| Degree of protection (IP) | IP20 |
| degree of impact strength (IK) | Not applicable |
| Storage temperature (Min-Max) | -10-70 °C |
| Source URL | https://www.bticino.com/products/bt-a5250s |
| Part Number | A5250S |
| BTicino Category | Ivory thermal magnetic and Salvavita circuit breakers |
| BTicino Taxonomy Path | Switches, sockets and wiring devices > Matix spare parts > Ivory colour devices > Ivory thermal magnetic and Salvavita circuit breakers |
| BTicino Series | Matix |
| Obsolete | No |
| New | No |
| Width | 47.1 mm |
| Depth | 47 mm |
| Height | 47 mm |
| Connection type | Screwed terminal |
| Rated current | 10 A |
| Width in number of modular spacings | 47.1 |
| Concurrently switching neutral conductor | No |
| Rated voltage | 230 V |
| Release characteristic | C |
| Number of poles (total) | 2 |
| Number of protected poles | 1 |
| Current limiting class | 1 |
| Ambient temperature during operating (Min-Max) | -5-50 °C |
| Connectable conductor cross section solid-core (Min-Max) | 2.5-2.5 mm² |
| Rated fault current | 0.01 A |
| Leakage current type | Other |
| Rated short-circuit breaking capacity according to EN 61009 | 3 kA |
| Rated short-circuit breaking capacity according to IEC 60947-2 | 3 kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 | 3 kA |
| Frequency | 50/60 Hz |
