Removable LED lamp
رقم القطعة: BT-R4380
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Removable LED lamp
المواصفات
| Mounting method | Built-in |
|---|---|
| Degree of protection (IP) | IP40 |
| degree of impact strength (IK) | IK04 |
| Operating / setting temperature (Min-Max) | -5-35 °C |
| Storage temperature (Min-Max) | -10-70 °C |
| Voltage type | AC |
| Nominal voltage (Min-Max) | 127-230 V |
| Frequency (Min-Max) | 50-60 Hz |
| Halogen free | Yes |
| Cable nature for connection | Flexible or rigid |
| With complemantary luminous signal | No |
| Vertical fixing center distance (Min-Max) | 3.5-3.7 mm |
| Horizontal fixing center distance (Min-Max) | 3-3.2 mm |
| Control mode | Not applicable |
| Contains Batteries and/or Accumulator | Yes |
| Addressable | No |
| Connected object | No |
| Source URL | https://www.bticino.com/products/bt-r4380 |
| Part Number | R4380 |
| BTicino Category | Removable Led lamp |
| BTicino Taxonomy Path | Switches, sockets and wiring devices > Classia standard range > Luminous and audible notification > Removable Led lamp |
| BTicino Series | Classia |
| Obsolete | No |
| New | No |
| Datasheet URL | https://assets.legrand.com/pim/NP-FT-GT/IDP000249_01-EN.pdf |
| Width | 45 mm |
| Length | 45.1 mm |
| Material cover | Plastic, opal |
| Terminal marking indication | No |
| Housing material | Plastic |
| Built-in width | 45 mm |
| Cable support | Screw cable clamp |
| Housing colour | White |
| Function | Escape route lighting/signage |
| Mandatory neutral | No |
| Battery ou Accumulator (Pack1) | Accumulator (rechargeable) |
| Element Composition (Pack1) | Nickel metal hydride |
| Number of Pack 1 | 1 |
| Number of Single Element (Pack1) | 1 |
| Single Element weight (Pack1) | 10 g |
| Pack1 Location | Product includes a battery |
| Regulation Type (Pack1) | P : Portable (Standard format) |
| Supplied remote control | No |
| Suitable for continuous circuit | Yes |
| With remote switch connection | No |
| Emergency function monitoring system | None |
| Emergency power supply system | Central (central battery) |
| Lamp type | LED not exchangeable |
| Protection class according to IEC 61140 | None |
| Rated luminous flux according to IEC 62722-2- 1 (Min-Max) | 0-0 lm |
| Nominal operation time (Min-Max) | 2-2 h |
| Height/depth | 44.6 mm |
| Built-in height/depth | 31 mm |
| Battery technology | NiMH |
| Built-in length | 45.1 mm |
| With pictogram | No |
| RAL-number housing | 9003 |
| Cable tie suitable with | Flexible conduit |
