Mil-Spec Coax, 75 Ohm, RG-179, 30 AWG Str SCCS, 95% SC Braid, FEP Jkt, Commercial Non-QPL

Belden

Mil-Spec Coax, 75 Ohm, RG-179, 30 AWG Str SCCS, 95% SC Braid, FEP Jkt, Commercial Non-QPL

رقم القطعة: 83264

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Mil-Spec Coax, 75 Ohm, RG-179, 30 AWG Str SCCS, 95% SC Braid, FEP Jkt, Commercial Non-QPL

المواصفات

Update and RevisionRevision Number: 0.506 Revision Date: 02-20-2026
Source URLhttps://www.belden.com/products/cable/broadcast-cable/sdi-video-coax-cable/83264
Belden Taxonomy Pathcable > broadcast-cable > sdi-video-coax-cable
Belden Categorycable
Belden Subcategorybroadcast-cable
Belden Sub-subcategorysdi-video-coax-cable
Datasheet URLhttps://catalog.belden.com/techdata/EN/83264_techdata.pdf
CEC / C(UL) Compliance.
FrequencyNom. Attenuation
Suitable ApplicationsAerospace, analog video
Max. Pull Tension17 lbs (7.7 kg)
Bulk Cable Weight10 lbs/1000ft
Environmental SuitabilityIndoor/Outdoor, Indoor, Outdoor, Aerial - When supported by messenger wire
European Directive ComplianceEU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC ComplianceChina RoHS II (GB/T 26572-2011)
FootnoteE - MAY CONTAIN MORE THAN 1 PIECE. MINIMUM LENGTH OF ANY ONE PIECE IS 25'., C - CRATE REEL PUT-UP.
RoHS Document URLhttps://catalog.belden.com/assets/docs/83264_rohs.pdf
Overall Cable Diameter (Nominal)0.100 in (2.54 mm)
SustainabilityCA Prop 65
RG Type179
FEP - Fluorinated Ethylene Propylene0.100 in (2.54 mm)
Military ComplianceCommercial, non-QPL product (M17/94-RG179)
