Rainbow Ribbon Cable .050" Pitch, 9R280XX Series, #28-25c, PVC Ins

Belden

Rainbow Ribbon Cable .050" Pitch, 9R280XX Series, #28-25c, PVC Ins

رقم القطعة: 9R28025

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Rainbow Ribbon Cable .050" Pitch, 9R280XX Series, #28-25c, PVC Ins

المواصفات

Update and RevisionRevision Number: 0.425 Revision Date: 09-07-2025
Source URLhttps://www.belden.com/products/cable/electronic-wire-cable/flat-ribbon-cable/9r28025
Belden Taxonomy Pathcable > electronic-wire-cable > flat-ribbon-cable
Belden Categorycable
Belden Subcategoryelectronic-wire-cable
Belden Sub-subcategoryflat-ribbon-cable
Datasheet URLhttps://catalog.belden.com/techdata/EN/9R28025_techdata.pdf
CEC / C(UL) Compliance.
Suitable ApplicationsInternal interconnection, internal wiring of electronic equipment, color-coded for quick identification & circuit tracing, easy breakouts for circuit routing, designed for mass-termination with standard IDC connectors
Bulk Cable Weight28 lbs/1000ft (42 kg/km)
Environmental SuitabilityIndoor
Flammability / Reaction to FireVW-1
European Directive ComplianceEU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC ComplianceChina RoHS II (GB/T 26572-2011)
RoHS Document URLhttps://catalog.belden.com/assets/docs/9R28025_rohs.pdf
AWM ComplianceAWM 20932
Frequency [MHz]Nom. Insertion Loss (Attenuation)
Conductor Spacing Center-Center Outside1.200 +/- .008 in
High Frequency Table (Nominal/Typical) NotesGS=Ground-Signal Mode; GSG=Ground-Signal-Ground Mode
Conductor Spacing Center-Center.050 +/- .003 in
