Category 3 Backbone Cable, 50 Pair, U/UTP, CMR

Name: Category 3 Backbone Cable, 50 Pair, U/UTP, CMR
Brand: Belden
SKU: DIW50

رقم القطعة: DIW50

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Category 3 Backbone Cable, 50 Pair, U/UTP, CMR

المواصفات

Update and Revision	Revision Number: 0.509 Revision Date: 07-30-2026
Source URL	https://www.belden.com/products/cable/ethernet-cable/category-3-cable/diw50
Belden Taxonomy Path	cable > ethernet-cable > category-3-cable
Belden Category	cable
Belden Subcategory	ethernet-cable
Belden Sub-subcategory	category-3-cable
Datasheet URL	https://catalog.belden.com/techdata/EN/DIW50_techdata.pdf
CEC / C(UL) Compliance	CMR.
Suitable Applications	Premise Backbone Cable, Ethernet 10BASE-T, Analog Phone, FAX
PVC - Polyvinyl Chloride	Western Electric Bound in 25 Pair Sub-Units, Binder 1: Blue/White, Binder 2: Orange/White
Max. Pull Tension	300 lbs (140 kg)
Bulk Cable Weight	179 lbs/1000ft
Environmental Suitability	Riser, Indoor
Flammability / Reaction to Fire	UL 1666 Riser, FT4
NEC / UL Compliance	CMR
European Directive Compliance	EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2017-07-10
APAC Compliance	China RoHS II (GB/T 26572-2011)
Notes	Electrical values are expected performance based on cable testing and representative performance within a typical Belden system. Print Includes Descending Footage/Meter Markings.
RoHS Document URL	https://catalog.belden.com/assets/docs/DIW50_rohs.pdf
CPR Compliance	CPR Euroclass: Eca
UK Regulation Compliance	UKCA Mark
Life Cycle	Discontinued - the product is no longer manufactured
Discontinuation Announcement Date	2014-11-11
Overall Cable Diameter (Nominal)	0.540 in (13.7 mm)
Stationary Min.	Installation Min.
Plenum Number	DPLN50
Material	Color Code
Max. Conductor DCR	Max. Capacitance Unbalance
Data Category	Category 3
TIA/EIA Compliance	ANSI/TIA-568.2-D Category 3
