Broadband Coax, Series 6, 18 AWG Solid BCCS, Quad Shield, FEP Jkt, CMP

Belden

Broadband Coax, Series 6, 18 AWG Solid BCCS, Quad Shield, FEP Jkt, CMP

رقم القطعة: 1152A

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Broadband Coax, Series 6, 18 AWG Solid BCCS, Quad Shield, FEP Jkt, CMP

المواصفات

Update and RevisionRevision Number: 0.467 Revision Date: 02-20-2026
Source URLhttps://www.belden.com/products/cable/video-cable/catv-cable/1152a
Belden Taxonomy Pathcable > video-cable > catv-cable
Belden Categorycable
Belden Subcategoryvideo-cable
Belden Sub-subcategorycatv-cable
Datasheet URLhttps://catalog.belden.com/techdata/EN/1152A_techdata.pdf
CEC / C(UL) ComplianceCMP.
FrequencyMin. Structural Return Loss
Suitable ApplicationsBroadband, Cable Television (CATV), RF drop cable, Over-The-Air (OTA) antennas
Max. Pull Tension192 lbs (87.1 kg)
Bulk Cable Weight45 lbs/1000ft
Environmental SuitabilityIndoor - Plenum, Indoor, Outdoor, Aerial - When supported by messenger wire, Burial
Flammability / Reaction to FireNFPA 262, FT6
NEC / UL ComplianceArticle 800, CMP
European Directive ComplianceEU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
APAC ComplianceChina RoHS II (GB/T 26572-2011)
NotesFor use in indoor plenum environments but also suitable for outdoor and underground applications.
FootnoteC - CRATE REEL PUT-UP.
RoHS Document URLhttps://catalog.belden.com/assets/docs/1152A_rohs.pdf
CPR ComplianceCPR Euroclass: Eca
UK Regulation ComplianceUKCA Mark
Overall Cable Diameter (Nominal)0.273 in (6.93 mm)
UL TemperatureOperating
Stationary Min.Installation Min.
Other Standard Compliance(s)ANSI/SCTE 74
SustainabilityCA Prop 65
RG Type6
FEP - Fluorinated Ethylene Propylene0.273 in (6.93 mm)
