BIX CONNECTOR 25-PAIR

Belden

BIX CONNECTOR 25-PAIR

رقم القطعة: A0393146

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

BIX CONNECTOR 25-PAIR

المواصفات

Weight0.11 g
Update and RevisionRevision Number: 0.91 Revision Date: 02-20-2026
Source URLhttps://www.belden.com/products/panels-patching-systems/copper-cross-connect-systems/category-5e-cross-connect-system/a0393146
Belden Taxonomy Pathpanels-patching-systems > copper-cross-connect-systems > category-5e-cross-connect-system
Belden Categorypanels-patching-systems
Belden Subcategorycopper-cross-connect-systems
Belden Sub-subcategorycategory-5e-cross-connect-system
Datasheet URLhttps://catalog.belden.com/techdata/EN/A0393146_techdata.pdf
Suitable ApplicationsIBDN System 1200, ISO Class E, 100BASE-T
NotesFor proper installation refer to Installation Guide PX100655 included with the product or visit our web site at http://www.belden.com
Operating Temperature Range-10°C To +60°C
Environmental SpaceIndoor
EU Directive ComplianceEU Directive 2002/95/EC (RoHS)
Suitability - IndoorYes
Storage Temperature Range-40°C To +70°C
TIA/EIA ComplianceANSI/TIA/EIA 568 C.2 Category 5e
Installation Temperature Range-10°C To +60°C
Third Party Performance VerificationETL - Verified Category 5e
Safety ListingACA,UL 1863 and CSA-C22.2
Related PartsCompatible with BIX patch cord, BIX Cross Connect System
Packagingpackaged in carton; Standard pack of 20 units
Current Rating1.5 A
Insulation Resistance100 MOhm*km
Connector System CompatibilityBIX
Tool CompatibilityBIX Connecting Tool (A0270165)
Dielectric Strength1,000V RMS @ 60 Hz for 1 minute kV DC
Max Contact Resistance1 mOhm
