1U 6 Duplex LC-PC (12 Fiber) OM3 Loaded Patch Panel with Splicing Tray – LSZH Partially Loaded

Name: 1U 6 Duplex LC-PC (12 Fiber) OM3 Loaded Patch Panel with Splicing Tray – LSZH Partially Loaded
Brand: Belden
SKU: LF13LD12L

رقم القطعة: LF13LD12L

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

1U 6 Duplex LC-PC (12 Fiber) OM3 Loaded Patch Panel with Splicing Tray – LSZH Partially Loaded

Overall Width	482.6 mm
Overall Height	43.2 ± 0.3 mm
Overall Depth	370 mm
Weight	4.5000 kg
Update and Revision	Revision Number: 0.6 Revision Date: 01-24-2024
Source URL	https://www.belden.com/products/panels-patching-systems/fiber-patch-systems/fiber-tools-accessories/lf13ld12l
Belden Taxonomy Path	panels-patching-systems > fiber-patch-systems > fiber-tools-accessories
Belden Category	panels-patching-systems
Belden Subcategory	fiber-patch-systems
Belden Sub-subcategory	fiber-tools-accessories
Datasheet URL	https://catalog.belden.com/techdata/EN/LF13LD12L_techdata.pdf
Suitable Applications	Fiber Express solution for Backbone, Telecommunication Room, Main Distribution room and Data centers
Operating Temperature Range	-10⁰C to +60⁰C
Environmental Space	Indoor
EU Directive 2011/65/EU (RoHS 2)	Yes
MII Order #39 (China RoHS)	EUP 50
Storage Temperature Range	-40⁰C to +70⁰C
Installation Temperature Range	-10⁰C to +60⁰C
Packaging	Individually packaged in a cardboard box
Connector System Compatibility	LC-PC
Front Connection	Flush
Max Capacity	6 LC Duplex Adapters (12 Ports)
Number of Ports	12 Port
Accessories inside panel	ABS injection-molded splice tray pre-loaded in the panel, Velcro Straps, Cable Ties, PG13.5 water joint, Splice tubing, Adapters 12 nos 2M Pigtails and Blanks
