Cable Assemblies - CAT6 Performance Modular Cord, 7 ft. (2.1 m)

Name: Cable Assemblies - CAT6 Performance Modular Cord, 7 ft. (2.1 m)
Brand: Belden
SKU: C6D1108007

رقم القطعة: C6D1108007

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Cable Assemblies - CAT6 Performance Modular Cord, 7 ft. (2.1 m)

المواصفات

Update and Revision	Revision Number: 0.251 Revision Date: 10-24-2025
Source URL	https://www.belden.com/products/patch-cords-cordsets-assemblies/copper-pre-term-assemblies/copper-patch-cords/c6d1108007
Belden Taxonomy Path	patch-cords-cordsets-assemblies > copper-pre-term-assemblies > copper-patch-cords
Belden Category	patch-cords-cordsets-assemblies
Belden Subcategory	copper-pre-term-assemblies
Belden Sub-subcategory	copper-patch-cords
Datasheet URL	https://catalog.belden.com/techdata/EN/C6D1108007_techdata.pdf
Suitable Applications	TIA Category 6, ISO Class E, 1000BASE-T, Support Power over Ethernet (up to 100W), Cisco UPOE (up to 60W) and Power over HDBase-T (up to 100W)
Notes	Belden 28 AWG cords meet TIA performance standards at reduced lengths with an attenuation de-rating value of 1.95. For guidelines and limitations on using 28 AWG cord for power delivery, see TIA-TSB-184-A-1. Cable weight: 0.012 Lbs/ft. This product may be protected by one or more patents. For further information, please visit: https://www.belden.com/patents .
Operating Temperature Range	-10°C To +60°C
Maximum Recommended Pulling Tension	11.250 lbs
Environmental Space	Indoor
MII Order #39 (China RoHS)	EUP 50
Suitability - Indoor	Yes
UL Voltage Rating	300 V RMS
Storage Temperature Range	-40°C To +70°C
IEEE Compliance	IEEE 802.3at type 1 and 2 (PoE) up to 30W, IEEE 802.3bt type 3 and 4 (PoE) up to 100W, CISCO (UPOE) up to 60W, Power over HDBaseT TM (POH) up to 100W
TIA/EIA Compliance	Category 6 - TIA-568.2-D ISO/IEC 11801-1
Installation Temperature Range	-10°C To +60°C
Other Standards	IEC 60603-7, ANSI/TIA 1096-A (formerly FCC Part 68-F)
Min Bend Radius (Overall Cable)	0.580 in
UL Rating	Riser
Safety Listing	c(UL)us Listed
Related Parts	CAT6+ Modular Jacks, CAT6+ RJ45 Couplers, CAT6+ Patch Panels
Packaging	Individually packaged in a clear plastic bag
Current Rating	1.500 A
Insulation Resistance	500 M-Ohm Minimum
EU Directive 2002/95/EC (RoHS)	Yes
Wiring Scheme	T568A/B-T568A/B
Boot	Polycarbonate - UL94V-0
Dielectric Strength	1,000 V RMS @ 60 Hz for 1 minute
Max Contact Resistance	20 mOhm
Plug /Jack Compatibility	RJ45
Labeling	Labeling: Belden Part Number and Cord Length
Overall Nominal Diameter	0.15 in
