Fiber Optic Cable OS2 Loose Tube 12 Cores Indoor/Outdoor LSZH Euroclass Cca s1a d1 a1

Name: Fiber Optic Cable OS2 Loose Tube 12 Cores Indoor/Outdoor LSZH Euroclass Cca s1a d1 a1
Brand: Legrand
SKU: 032526

رقم القطعة: 032526

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Fiber Optic Cable OS2 Loose Tube 12 Cores Indoor/Outdoor LSZH Euroclass Cca s1a d1 a1

المواصفات

RAL-number	1018
Operating / setting temperature (Min-Max)	-40-70 °C
Storage temperature (Min-Max)	-40-70 °C
Source URL	https://www.legrand.com/ecatalogue/en/catalog/products/fiber-optic-cable-os2-loose-tube-12-cores-indooroutdoor-lszh-euroclass-cca-s1a-d1-a1-032526
Legrand Category	Fibre optic cables
Legrand Taxonomy Path	Security, communication and networks > IT networks > Fiber optic solutions (drawers, panels, connectors...) > Fibre optic cables
Datasheet URL	https://assets.legrand.com/pim/Certif/LGBVPQENQF.PDF
With strain relief	No
Fibre type	Single mode 9/125
Category	OS2
Number of fibres	12
Colour outer sheath	Yellow
Flame retardant according to IEC 60332-3-24 (Cat C)	Yes
With rodent protection	No
Type of tube	Loose tube
Number of fibres per tube	12
Material outer sheath	Other
Specification material outer sheath	Other
Longitudinal water blocking cable	Yes
Radial water blocking cable	Yes
Cable metal free	Yes
Cable geometry	Round
Flame retardant according to IEC 60332-1-2	Yes
Flame retardant according to IEC 60332-3-21 (Cat A F/R)	No
Flame retardant according to IEC 60332-3-22 (Cat A)	No
Flame retardant according to IEC 60332-3-23 (Cat B)	No
Flame retardant according to IEC 60332-3-25 (Cat D)	No
Low smoke according to EN IEC 61034-2	Yes
Halogen free according to EN IEC 60754-1	No
Halogen free according to EN IEC 60754-2	Yes
Halogen free according to EN IEC 60754-3	No
Reaction-to-fire according to EN 13501-6: Class	Cca
Reaction-to-fire according to EN 13501-6: Smoke production	s1a
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	D1
Reaction-to-fire according to EN 13501-6: Acidity	a1
Circuit integrity according to IEC 60331-23	No
Circuit integrity according to IEC 60331-25	None
Circuit integrity according to EN 50200	None
Oil resistant according to EN IEC 60811-404	No
Resistant to chemicals	No
Cable width approximate	9.4 mm
Cable height approximate	9.4 mm
Outer diameter approximate	9.4 mm
Min. permitted bending radius, stationary application/permanent installation	100 mm
Max. tensile strength during installation	3 kN
Suitable for underground installation	No
Blow in	No
Weight	73 kg/km
Fibre optic cable colour coding according to S-12 Skanova standard	No
