Galion - 1 gang double USB 2,4A type-A USB chargers - White

Name: Galion - 1 gang double USB 2,4A type-A USB chargers - White
Brand: Legrand
SKU: 282447

رقم القطعة: 282447

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Galion - 1 gang double USB 2,4A type-A USB chargers - White

Mounting method	Flush-mounted
Built-in depth	30.9 mm
Colour	White
degree of impact strength (IK)	IK04
Operating / setting temperature (Min-Max)	-5-45 °C
Storage temperature (Min-Max)	-10-70 °C
Halogen free	Yes
Source URL	https://www.legrand.com/ecatalogue/en/catalog/products/galion-1-gang-double-usb-24a-type-usb-chargers-white-282447
Legrand Category	USB socket,Power outlet, USB outlet, data outlet and other outlets
Legrand Taxonomy Path	Wiring devices, connected home and building control > Home and building wiring devices > Sockets, USB sockets, data sockets and other sockets > USB socket
Datasheet URL	https://assets.legrand.com/pim/Certif/LGGNNSNVTR.PDF
Model	Other
Frequency (Min-Max)	50-60 Hz
Mandatory neutral	Yes
Connection type	Screwed terminal
Voltage type	AC
Suitable for degree of protection (IP)	IP20
Terminal marking indication	Yes
Terminals capacity (Min-Max)	1-4 mm²
Device width	86 mm
Device height	88 mm
Device depth	40 mm
Standby consumption	0.4 mA
Max. output current	3000 mA
Operating voltage (Min-Max)	100-240 V
Stress test conformity (1000V)	Yes
Antimicrobial treatment	No
Number of terminals	2
Number of modules (module system)	2
Min. depth of built-in installation box	30 mm
Number of ports USB-A	2
Number of empty module positions	0
Power Delivery	No
USB Output Power	12
