Galion - 2 gangs British Standard switched single pole socket outlet with power indicator - 13A - Wh

Name: Galion - 2 gangs British Standard switched single pole socket outlet with power indicator - 13A - Wh
Brand: Legrand
SKU: 282481

رقم القطعة: 282481

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Galion - 2 gangs British Standard switched single pole socket outlet with power indicator - 13A - White

المواصفات

Mounting method	Flush-mounted
Built-in depth	15.2 mm
Colour	White
degree of impact strength (IK)	IK04
Operating / setting temperature (Min-Max)	-5-50 °C
Storage temperature (Min-Max)	-10-70 °C
Halogen free	Yes
Source URL	https://www.legrand.com/ecatalogue/en/catalog/products/galion-2-gangs-british-standard-switched-single-pole-socket-outlet-with-power-indicator-13a-white-282481
Legrand Category	Power outlet, USB outlet, data outlet and other outlets,Bristish Standard
Legrand Taxonomy Path	Wiring devices, connected home and building control > Wiring devices ranges > Galion (British Standard) > Power outlet, USB outlet, data outlet and other outlets
Datasheet URL	https://assets.legrand.com/pim/Certif/LGBAPTMTOQ.PDF
Material	Plastic
Surface protection	Untreated
Model	British Standard
Surface finishing	Glossy
Material quality	Thermoplastic
Assembly arrangement	Basic element with full cover plate
Frequency (Min-Max)	50-60 Hz
Connection type	Screwed terminal
Type of fastening	Mounting with screw
Cable section (Min-Max)	1-4 mm²
Transparent	No
Voltage type	AC
Suitable for degree of protection (IP)	IP20
Terminal marking indication	Yes
Terminals capacity (Min-Max)	1-4 mm²
Device width	146 mm
Connected object	No
Device height	88 mm
Device depth	27.2 mm
Compatible with Apple HomeKit	No
Compatible with Google Assistant	No
Compatible with Amazon Alexa	No
IFTTT support available	No
Antimicrobial treatment	No
Cable nature for connection	Flexible or rigid
With hinged lid	No
Protective contact	Flat
With enhanced contact protection	Yes
Number of socket outlets	2
With complemantary luminous signal	Yes
Number of active contacts (round)	0
Number of active contacts (flat)	4
Number of active contacts (square)	0
Nominal current	13 A
Nominal voltage	250 V
Concurrently switching neutral conductor	No
Lockable	No
Imprint/indication	Scanable symbol/barrier free
With on/off switch	Yes
With orientation lighting	No
Number of modules (module system)	4
Min. depth of built-in installation box	25 mm
Insulated mounting	No
With miniature fuse	No
Overvoltage protection	No
Number of ports USB-A	0
Number of empty module positions	0
Power Delivery	No
Number of socket outlets switchable	2
Number of phases	1
Metallic colour	No
Eject-mechanism	No
With function lighting	Yes
Fault current protection	No
Special power supply	None
With Wi-Fi signal repeater	No
With built-in bluetooth speaker	No
