Eloe - 1 gang RJ11 socket - Glossy white finish - Toolless fast-connection 110 terminals - Flush-mou

Name: Eloe - 1 gang RJ11 socket - Glossy white finish - Toolless fast-connection 110 terminals - Flush-mou
Brand: Legrand
SKU: 618097

رقم القطعة: 618097

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Eloe - 1 gang RJ11 socket - Glossy white finish - Toolless fast-connection 110 terminals - Flush-mounted IP20 indoor residential use

Mounting method	Flush-mounted
Built-in depth	20.4 mm
Colour	White
RAL-number	9003
Degree of protection (IP)	IP20
degree of impact strength (IK)	IK04
Operating / setting temperature (Min-Max)	-5-50 °C
Storage temperature (Min-Max)	-10-70 °C
Halogen free	Yes
Source URL	https://www.legrand.com/ecatalogue/en/catalog/products/eloe-1-gang-rj11-socket-glossy-white-finish-toolless-fast-connection-110-terminals-flush-mounted-ip20-indoor-residential-use-618097
Legrand Category	Other outlets (audio/video, loudspeaker, TV, phone...),Power outlet, USB outlet, data outlet and other outlets
Legrand Taxonomy Path	Wiring devices, connected home and building control > Home and building wiring devices > Sockets, USB sockets, data sockets and other sockets > Other outlets (audio/video, loudspeaker, TV, phone...)
Datasheet URL	https://assets.legrand.com/pim/DOCUMENT/ex223001_0663.pdf
Assembly arrangement	Basic element
Connection type	110
Type of fastening	Engage (snap)
Terminal marking indication	Yes
Device width	86 mm
Device height	86 mm
Device depth	31.9 mm
Antimicrobial treatment	No
Flush-mounted installation	Yes
With label space	No
Type of connector	Other
Surface mounting	No
Shielded housing	No
Separate earthing connection	No
Mounting method shielding connection	None
Outlet direction	Straight
With dust cover	Yes
With terminal resistor	No
Colour coding	Yes
Horizontal fixing center distance (Min-Max)	60.3-60.3 mm
Number of modules (module system)	1
