Art d'Arnould - 1 gang television socket TV-R-SAT socket Epure - Satin White

Name: Art d'Arnould - 1 gang television socket TV-R-SAT socket Epure - Satin White
Brand: Legrand
SKU: AR-68345

رقم القطعة: AR-68345

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Art d'Arnould - 1 gang television socket TV-R-SAT socket Epure - Satin White

Mounting method	Flush-mounted
Colour	White
Degree of protection (IP)	IP21
degree of impact strength (IK)	IK02
Operating / setting temperature (Min-Max)	-5-35 °C
Storage temperature (Min-Max)	-10-70 °C
Halogen free	Yes
Source URL	https://www.legrand.com/ecatalogue/en/catalog/products/art-darnould-1-gang-television-socket-tv-r-sat-socket-epure-satin-white-ar-68345
Legrand Category	Other outlets (audio/video, loudspeaker, TV, phone...),Power outlet, USB outlet, data outlet and other outlets
Legrand Taxonomy Path	Wiring devices, connected home and building control > Home and building wiring devices > Sockets, USB sockets, data sockets and other sockets > Other outlets (audio/video, loudspeaker, TV, phone...)
Datasheet URL	https://assets.legrand.com/pim/DOCUMENT/ex223001_0715.pdf
Material	Metal
Surface protection	Lacquered
Model	End socket
Surface finishing	Matt
Material quality	Brass
Assembly arrangement	Basic element with full cover plate
Type of fastening	Mounting with screw
RAL-number (similar)	9003
Device width	86 mm
Device height	86 mm
Device depth	39.5 mm
Antimicrobial treatment	No
Min. depth of built-in installation box	40 mm
Suitable for remote power supply	Yes
Type of socket outlet	TV/RD/SAT
DAB+	Yes
Tap loss at 860 MHz	1.5 dB
Tap loss at 2150 MHz	2 dB
Number of outlets	3
Suitable for cable modem	No
Radio frequency band (Min-Max)	87.5-240 MHz
SAT frequency band (Min-Max)	950-2400 MHz
