Valena Life - Double USB Type C+C charging outlets - 2 USB Type C ports 3A 15W - 100-240V AC flush-m

Name: Valena Life - Double USB Type C+C charging outlets - 2 USB Type C ports 3A 15W - 100-240V AC flush-m
Brand: Legrand
SKU: 753107

رقم القطعة: 753107

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Valena Life - Double USB Type C+C charging outlets - 2 USB Type C ports 3A 15W - 100-240V AC flush-mounted - White IP40 housing

Mounting method	Flush-mounted
Built-in depth	33 mm
Colour	White
RAL-number	9003
degree of impact strength (IK)	IK04
Operating / setting temperature (Min-Max)	5-40 °C
Storage temperature (Min-Max)	-20-70 °C
Halogen free	Yes
Source URL	https://www.legrand.com/ecatalogue/en/catalog/products/valena-life-double-usb-type-cc-charging-outlets-2-usb-type-ports-3a-15w-100-240v-ac-flush-mounted-white-ip40-housing-753107
Legrand Category	USB Sockets
Legrand Taxonomy Path	Wiring devices, connected home and building control > Wiring devices ranges > Valena Life > USB Sockets
Datasheet URL	https://assets.legrand.com/pim/NP-FT-GT/F02713EN-01.pdf
Model	Other
Frequency (Min-Max)	50-60 Hz
Mandatory neutral	Yes
Connection type	Screwed terminal
Cable section (Min-Max)	1.5-2.5 mm²
Voltage type	AC
Suitable for degree of protection (IP)	IP40
Terminal marking indication	Yes
Terminals capacity (Min-Max)	1.5-2.5 mm²
Device width	75 mm
Device height	75 mm
Device depth	42 mm
Power consumption	0.064 W
Max. output current	3000 mA
Operating voltage (Min-Max)	100-240 V
Supply current (Min-Max)	0.5-0.5 A
Stress test conformity (1000V)	No
Antimicrobial treatment	No
Cable nature for connection	Flexible or rigid
Wireless	No
Number of terminals	2
Output voltage (Min-Max)	5-5 V
Number of modules (module system)	1
Min. depth of built-in installation box	40 mm
Number of ports USB-A	0
Number of empty module positions	2
Power Delivery	No
USB Output Power	15
