THREE-WAY SWITCH - 250V ac - 2P - 10AX - NEUTRAL BUTTON KEY - 6 TERMINALS - 1 MODULE - GLOSSY WHITE

Name: THREE-WAY SWITCH - 250V ac - 2P - 10AX - NEUTRAL BUTTON KEY - 6 TERMINALS - 1 MODULE - GLOSSY WHITE
Brand: GEWISS
SKU: GW10122AB

رقم القطعة: GW10122AB

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

THREE-WAY SWITCH - 250V ac - 2P - 10AX - NEUTRAL BUTTON KEY - 6 TERMINALS - 1 MODULE - GLOSSY WHITE - ANTIBACTERIAL - CHORUSMART

Colour	Glossy white
Material	Antibacterial tecnopolymer
Glow Wire Test	850 °C
Standard	EN 60669-1
Ware Number	85365080
Source URL	https://www.gewiss.com/ww/en/products/product.1000000.1007471.GW10122AB
GEWISS Family	Building
GEWISS Series	CHORUSMART - Domestic range-Antibacterial range
GEWISS Taxonomy Path	Building > CHORUSMART - Domestic range-Antibacterial range
Datasheet URL	https://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000000.1007471.GW10122AB.pdf
Electrocod	0130
Insulation resistance	> 5 MOhm
Description	2P - 10 AX
Category	Three-way switch
Button key	Neutral
Voltage	250 V ac
Resistance at test voltage	2000 V at 50 Hz for 1 minute
Rated power of 230V LED lamps	100 W
Wiring terminals	With screw
Prolonged operation switch (no.of position changes)	40.000 at In 250 V ac cosφ=0.6
Thermo-pressure with ball	125 °C
Terminal grip on cable traction	> 50 N
Terminal tightening capacity stranded cables (mm²)	min. 0.75 - max. 2x4
Terminal tightening capacity solid cables (mm²)	min. 0.5 - max. 2x2.5
No. modules	1
Symbol	UP - DOWN
