EURO-AMERICAN STANDARD SHAVER SOCKET-OUTLET WITH INSULATION TRANSFORMER - 230V ac - 50/60 Hz - 3 MOD

Name: EURO-AMERICAN STANDARD SHAVER SOCKET-OUTLET WITH INSULATION TRANSFORMER - 230V ac - 50/60 Hz - 3 MOD
Brand: GEWISS
SKU: GW10331

رقم القطعة: GW10331

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

EURO-AMERICAN STANDARD SHAVER SOCKET-OUTLET WITH INSULATION TRANSFORMER - 230V ac - 50/60 Hz - 3 MODULES - GLOSSY WHITE - CHORUSMART

Colour	Glossy white
Material	Technopolymer
Glow Wire Test	850 °C
Standard	Euro-American
Ware Number	85366990
Source URL	https://www.gewiss.com/ww/en/products/product.1000000.1000040.GW10331
GEWISS Family	Building
GEWISS Series	CHORUSMART - Domestic range-Glossy white modular devices
GEWISS Taxonomy Path	Building > CHORUSMART - Domestic range-Glossy white modular devices
Datasheet URL	https://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000000.1000040.GW10331.pdf
Electrocod	0131
Insulation resistance	> 5 MOhm
Description	With isolation transformer
Category	Shaver socket-outlet
Resistance at test voltage	2000 V at 50 Hz for 1 minute
Wiring terminals	With screw
Thermo-pressure with ball	125 °C
Terminal grip on cable traction	> 50 N
Terminal tightening capacity stranded cables (mm²)	min. 0.75 - max. 2x4
Terminal tightening capacity solid cables (mm²)	min. 0.5 - max. 2x2.5
No. modules	3
For plug pins	Ø 4 / 5 - 6.3x1.5 mm
Socket-out type	P11-USA
Selectable output voltage	120-230 V ac
Maximum power	20 VA
Supply voltage	230 V ac - 50/60 Hz
