INTERLOCKED SWITCHED SOCKET-OUTLET - 2P+E 16A - P40 - WITH RESID.CURRENT CIRCUIT BREAKER 1P+N 16A -

GEWISS

INTERLOCKED SWITCHED SOCKET-OUTLET - 2P+E 16A - P40 - WITH RESID.CURRENT CIRCUIT BREAKER 1P+N 16A -

رقم القطعة: GW13322

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

INTERLOCKED SWITCHED SOCKET-OUTLET - 2P+E 16A - P40 - WITH RESID.CURRENT CIRCUIT BREAKER 1P+N 16A - 230Vac - 4 MODULES - NAT. SATIN BEIGE - CHORUSMART

المواصفات

ColourNatural satin beige
MaterialTechnopolymer
TypeInterlocked
Glow Wire Test850 °C
StandardEnglish
Ware Number85366990
Source URLhttps://www.gewiss.com/ww/en/products/product.1000000.1007728.GW13322
GEWISS FamilyBuilding
GEWISS SeriesCHORUSMART - domestic range-Satin natural beige modular devices
GEWISS Taxonomy PathBuilding > CHORUSMART - domestic range-Satin natural beige modular devices
Datasheet URLhttps://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000000.1007728.GW13322.pdf
Electrocod0131
Insulation resistance> 5 MOhm
Description2P+E - 16 A
CategoryDual amperage interlocked socket-outlet
Voltage230 V ac
Resistance at test voltage2000 V at 50 Hz for 1 minute
Wiring terminalsWith screw
Thermo-pressure with ball125 °C
Terminal grip on cable traction> 50 N
Terminal tightening capacity stranded cables (mm²)min. 0.75 - max. 2x4
Terminal tightening capacity solid cables (mm²)min. 0.5 - max. 2x2.5
No. modules4
Socket-out typeP40
Prolonged operation socket (no.of position changes)10.000 at In 250 V ac cosφ=0.8
ProtectionMagnetotermico + Differenziale
Miniature circuit breakers1P+N 16 A
Breaking capacity3 kA
Idn10 mA
