EURO-AMERICAN STANDARD SHAVER SOCKET-OUTLET WITH INSULATION TRANSFORMER - 230V ac - 50/60 Hz - 3 MOD

GEWISS

EURO-AMERICAN STANDARD SHAVER SOCKET-OUTLET WITH INSULATION TRANSFORMER - 230V ac - 50/60 Hz - 3 MOD

رقم القطعة: GW14331

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

EURO-AMERICAN STANDARD SHAVER SOCKET-OUTLET WITH INSULATION TRANSFORMER - 230V ac - 50/60 Hz - 3 MODULES - TITANIUM - CHORUSMART

المواصفات

ColourGlossy Titanium
MaterialTechnopolymer
StandardEuro-American
Ware Number85366990
Source URLhttps://www.gewiss.com/ww/en/products/product.1000000.1000042.GW14331
GEWISS FamilyBuilding
GEWISS SeriesCHORUSMART - Domestic range-Glossy titanium modular devices
GEWISS Taxonomy PathBuilding > CHORUSMART - Domestic range-Glossy titanium modular devices
Datasheet URLhttps://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000000.1000042.GW14331.pdf
Electrocod0131
Insulation resistance> 5 MOhm
DescriptionWith isolation transformer
CategoryShaver socket-outlet
Resistance at test voltage2000 V at 50 Hz for 1 minute
Wiring terminalsWith screw
Thermo-pressure with ball125 °C
Terminal grip on cable traction> 50 N
Terminal tightening capacity stranded cables (mm²)min. 0.75 - max. 2x4
Terminal tightening capacity solid cables (mm²)min. 0.5 - max. 2x2.5
No. modules3
For plug pinsØ 4 / 5 - 6.3x1.5 mm
Socket-out typeP11-USA
Selectable output voltage120-230 V ac
Maximum power20 VA
Supply voltage230 V ac - 50/60 Hz
