EMPTY ENCLOSURE FOR PUSH-BUTTONS, CONTROLS AND INDICATORS - 2 GANG - DIAMETER 22mm - GREY RAL 7035 L

GEWISS

EMPTY ENCLOSURE FOR PUSH-BUTTONS, CONTROLS AND INDICATORS - 2 GANG - DIAMETER 22mm - GREY RAL 7035 L

رقم القطعة: GW27102

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

EMPTY ENCLOSURE FOR PUSH-BUTTONS, CONTROLS AND INDICATORS - 2 GANG - DIAMETER 22mm - GREY RAL 7035 LID - IP66

المواصفات

ColourGrey RAL 7035
Glow Wire Test650 °C
StandardEN 60670-1
Ware Number85381000
Source URLhttps://www.gewiss.com/ww/en/products/product.1000002.1000082.GW27102
GEWISS FamilyInstallation
GEWISS Series74 PS Range-Push-buttons, selectors and indicators Ø 22 mm
GEWISS Taxonomy PathInstallation > 74 PS Range-Push-buttons, selectors and indicators Ø 22 mm
Datasheet URLhttps://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000002.1000082.GW27102.pdf
Electrocod0212
GEWISS FamiliesInstallation, Building
GEWISS Taxonomy PathsInstallation > 74 PS Range-Push-buttons, selectors and indicators Ø 22 mm | Building > 27 COMBI Range-Wall-mounting enclosures and modular components
GEWISS Series (all)74 PS Range-Push-buttons, selectors and indicators Ø 22 mm | 27 COMBI Range-Wall-mounting enclosures and modular components
IP degreeIP66
DescriptionFor push button
Outer dim. LxHxD (mm)132x82x65
Thermo-pressure with ball70 °C
Type of knockout holesRemovable with tool
Insulation classII
Mechanical resistanceIK07
Lid screwsStainless steel
Torque screws tightening0.8 NM
Installation temperature-25 +60 °C
No. gangs2
Side entries6xØ 23
Top entries1xØ 23
Bottom entries1xØ 23
