DISTRIBUTION BOARD - GERMAN STANDARD - (12X3)36MODULES - IP65 - TERMINAL BLOCK AND INTERCHANGEABLE F

GEWISS

DISTRIBUTION BOARD - GERMAN STANDARD - (12X3)36MODULES - IP65 - TERMINAL BLOCK AND INTERCHANGEABLE F

رقم القطعة: GW40125

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

DISTRIBUTION BOARD - GERMAN STANDARD - (12X3)36MODULES - IP65 - TERMINAL BLOCK AND INTERCHANGEABLE FLANGES - WITH SMOKED TRANSPARENT DOOR

المواصفات

ColourGrey RAL 7035
Glow Wire Test750 °C
StandardIEC EN 60670-1; IEC EN 60670-24; DIN VDE 0603-1
Ware Number85381000
Source URLhttps://www.gewiss.com/ww/en/products/product.1000002.1000086.GW40125
GEWISS FamilyInstallation
GEWISS Series40 CDE-Enclosures and distribution boards for country-specific standards
GEWISS Taxonomy PathInstallation > 40 CDE-Enclosures and distribution boards for country-specific standards
Datasheet URLhttps://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000002.1000086.GW40125.pdf
Operating temperature-25 +60 °C
IP degreeIP65
Outer dim. LxHxD (mm)298x570x140
Thermo-pressure with ball70 °C
Insulation classII
Mechanical resistanceIK07
InstallationWall mounting
No. of modules EN 5002236 (12x3)
Door colourSmoked Transparent
Pole 1 (mm²)N (6x35)+(20x10)
Pole 2 (mm²)E (6x35)+(20x10)
Terminal block N (mm²)(6x25)+(20x10)
Terminal block T (mm²)(6x25)+(20x10)
