FIXED INTERLOCKED HORIZONTAL SOCKET-OUTLET - WITH BOTTOM - WITH FUSE-HOLDER BASE - 3P+E 16A 200-250V
رقم القطعة: GW66027
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
FIXED INTERLOCKED HORIZONTAL SOCKET-OUTLET - WITH BOTTOM - WITH FUSE-HOLDER BASE - 3P+E 16A 200-250V - 50/60HZ 9H CBF - IP44
المواصفات
| Colour | Blue |
|---|---|
| Type | Horizontal |
| Glow Wire Test | 850 °C (active parts) - 650 °C (passive parts) |
| Ware Number | 85366990 |
| Source URL | https://www.gewiss.com/ww/en/products/product.1000002.1000076.GW66027 |
| GEWISS Family | Installation |
| GEWISS Series | IB Range-Interlocked socket-outlets IEC 309 standard |
| GEWISS Taxonomy Path | Installation > IB Range-Interlocked socket-outlets IEC 309 standard |
| Datasheet URL | https://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000002.1000076.GW66027.pdf |
| Electrocod | 2220 |
| Operating temperature | -25 +40 °C |
| IP degree | IP44 |
| Thermo-pressure with ball | 125 °C (active parts) - 80 °C (passive parts) |
| Protection | Fuse-holder base (CBF) |
| Frequency | 50/60 Hz |
| Rated current (A) | 16 |
| No. of poles | 3P+E |
| Mechanical resistance | IK08 |
| Rated voltage | 200 - 250 V |
| Reference h | 9 |
| With back-mounting box | Yes |
| Fuse breacking capacity | > 50 kA |
| Fuses holder | E14 |
