VERTICAL FIXED INTERLOCKED SOCKET OUTLET - WITH BOTTOM - WITH FUSE-HOLDER BASE - 3P+E 32A 480-500V -

GEWISS

VERTICAL FIXED INTERLOCKED SOCKET OUTLET - WITH BOTTOM - WITH FUSE-HOLDER BASE - 3P+E 32A 480-500V -

رقم القطعة: GW66243N

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

VERTICAL FIXED INTERLOCKED SOCKET OUTLET - WITH BOTTOM - WITH FUSE-HOLDER BASE - 3P+E 32A 480-500V - 50/60HZ 7H - IP67

المواصفات

ColourBlack
TypeVertical
Glow Wire Test850 °C (IB socket) - 650 °C (bottom)
Ware Number85366990
Source URLhttps://www.gewiss.com/ww/en/products/product.1000002.1000076.GW66243N
GEWISS FamilyInstallation
GEWISS SeriesIB Range-Interlocked socket-outlets IEC 309 standard
GEWISS Taxonomy PathInstallation > IB Range-Interlocked socket-outlets IEC 309 standard
Datasheet URLhttps://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000002.1000076.GW66243N.pdf
Electrocod2222
Operating temperature-25 +40 °C
IP degreeIP67
Thermo-pressure with ball125 °C (IB socket) - 80 °C (bottom)
ProtectionFuse-holder base (CBF)
Frequency50/60 Hz
Rated current (A)32
No. of poles3P+E
Mechanical resistanceIK08
Rated voltage480 - 500 V
Reference h7
With back-mounting boxYes
Fuse breacking capacity> 50 kA
IB socket outlet rated current (In)27 A
Type of fuseØ 10.3x38 mm
Rated insulation voltage (Ui)500 V
Breaking capacity (Icc)10 kA
WeightMax. 1.1 Kg
Rated impulse withstand voltage (Uimp)4 kV
