VERTICAL FIXED INTERLOCKED SOCKET OUTLET - WITHOUT BOTTOM - WITH FUSE-HOLDER BASE - 3P+N+E 63A 100-1

GEWISS

VERTICAL FIXED INTERLOCKED SOCKET OUTLET - WITHOUT BOTTOM - WITH FUSE-HOLDER BASE - 3P+N+E 63A 100-1

رقم القطعة: GW66347N

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

VERTICAL FIXED INTERLOCKED SOCKET OUTLET - WITHOUT BOTTOM - WITH FUSE-HOLDER BASE - 3P+N+E 63A 100-130V - 50/60HZ 4H - IP67

المواصفات

ColourYellow
TypeVertical
Glow Wire Test850 °C
Ware Number85366990
Source URLhttps://www.gewiss.com/ww/en/products/product.1000002.1000076.GW66347N
GEWISS FamilyInstallation
GEWISS SeriesIB Range-Interlocked socket-outlets IEC 309 standard
GEWISS Taxonomy PathInstallation > IB Range-Interlocked socket-outlets IEC 309 standard
Datasheet URLhttps://www.gewiss.com/content/gewiss/ww/en/products/product.datasheet.1000002.1000076.GW66347N.pdf
Electrocod2222
Operating temperature-25 +40 °C
IP degreeIP67
Thermo-pressure with ball125 °C
ProtectionFuse-holder base (CBF)
Frequency50/60 Hz
Rated current (A)63
No. of poles3P+N+E
Mechanical resistanceIK08
Rated voltage100 - 130 V
Reference h4
With back-mounting boxNo
Fuse breacking capacity> 50 kA
IB socket outlet rated current (In)48 A
Type of fuseØ 22x58 mm
Rated insulation voltage (Ui)500 V
Breaking capacity (Icc)10 kA
WeightMax. 2.2 Kg
Rated impulse withstand voltage (Uimp)4 kV
