24 Motor Grader

Name: 24 Motor Grader
Brand: Caterpillar
SKU: CAT-1000034758

رقم القطعة: CAT-1000034758

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

24 Motor Grader

Engine Model	Cat C27
Bore	137.2 mm
Stroke	152.4 mm
Displacement	27.03 l
Note (1)	Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture.
Note (2)	Optimized VHP Plus is standard for the 24.
Note (3)	Net power advertised is the power available at rated speed of 1,800 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator.
Note (4)	Power as declared per ISO 14396. Rated rpm 1,800 (561 hp)
Air Conditioning	The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas.
Model	24
Product Page	https://www.cat.com/en_US/products/new/equipment/motor-graders/motor-graders/1000034758.html
Caterpillar Category	Motor Graders
Caterpillar Category Path	Products > Equipment > Motor Graders > Motor Graders > 24
Caterpillar Product Family	equipment
Caterpillar Product Page ID	1000034758
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20210211-fcf6a-0ca6d
Emissions	Tier 4 Final/Stage IV or Equivalent to Tier 2/Stage II
Number of Cylinders	12
Standard Capability	50 °C
Operating Weight - Typically Equipped	74985 kg
Blade Width	7.3 m
Net Power - EEC 80/1269	399 kW
Blade Height	1025 mm
Maximum Depth of Cut	550 mm
Maximum Lift Above Ground	410 mm
