R2900 XE Underground Diesel-Electric LHD Loader

Caterpillar

R2900 XE Underground Diesel-Electric LHD Loader

رقم القطعة: CAT-112580

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

R2900 XE Underground Diesel-Electric LHD Loader

المواصفات

Engine ModelCat® C15
Bore137 mm
Stroke172 mm
Displacement15.2 l
Note (1)Power ratings apply at a rated speed of 1,600 rpm for Tier 2/Stage II model engine when tested under the reference conditions for the specified standard.
Note (2)Power ratings apply at a rated speed of 1,600 rpm for Stage V model engine when tested under the reference conditions for the specified standard.
Note (3)All rating conditions are based on ISO/TR 14396, inlet air standard conditions with a total barometric pressure of 100 kPa (29.5 in Hg), with a vapor pressure of 1 kPa (.295 in Hg), and 25° C (77° F). Performance measured using fuel to EPA specifications in 40 CFR Part 1065 and EU specifications in Directive 97/68/EC with a density of 0.845-0.850 kg/L @ 15° C (59° F) and fuel inlet temperature 40° C (104° F).
Note (4)Minimal engine derating* required up to 2926 m (9,600 ft) at rated speed for Stage V engines and 3505 m (11,500 ft) for Tier 2/Stage II equivalent engines.
Note (5)Optional DPF (Diesel Particulate Filter) Package available.
Note (6)* <5%
Note* Calculated Weight.
Fuel Tank660 l
DEF Tank34 l
Engine Crankcase52 l
ModelR2900 XE (Diesel-Electric)
Product Pagehttps://www.cat.com/en_US/products/new/equipment/underground-hard-rock/underground-mining-load-haul-dump-lhd-loaders/112580.html
Caterpillar CategoryUnderground Mining Load Haul Dump (LHD) Loaders
Caterpillar Category PathProducts > Equipment > Underground - Hard Rock > Underground Mining Load Haul Dump (LHD) Loaders > R2900 XE (Diesel-Electric)
Caterpillar Product Familyequipment
Caterpillar Product Page ID112580
Datasheet URLhttps://s7d2.scene7.com/is/content/Caterpillar/CM20251023-d2dd9-f00d2
Axle Oscillation8°
Hydraulic Tank338 l
StandardsISO 3471:2008 ROPS; ISO 3449:2005 FOPS
Total Cycle Time15.3 s
Shipping Weight59869 kg
Nominal Payload Capacity18500 kg
Gross Machine Mass78089 kg
Static Tipping Load - Straight Ahead - Lift Arms Horizontal43276 kg
Static Tipping Load - Full Turn - Lift Arms Horizontal37598 kg
Operating Mass*55462 kg
Operating Mass* - Front Axle24685 kg
Operating Mass* - Rear Axle30777 kg
Operating Mass + Rated Payload*73962 kg
Operating Mass + Rated Payload* - Front Axle54480 kg
Operating Mass + Rated Payload* - Rear Axle19482 kg
Raise9 s
Dump2.8 s
Lower, Empty, Float Down3.5 s
Dump Bucket - 28.6 m³
Dump Bucket - 49.8 m³
Engine Power - Stage V Engine - ISO 14396:2002335 kW
Breakout Force - Tilt (ISO)42000 kg
Outside Clearance Radius7270 mm
Breakout Force - Lift (ISO)32500 kg
Inner Clearance Radius3391 mm
Bucket Capacities7.4-9.8 m³ (9.7-12.8 yd³)
Articulation Angle42.5°
Dump Bucket - 1 - Standard Bucket7.4 m³
Tire Size29.5 R29
Dump Bucket - 39.2 m³
Lift/Tilt System - CircuitElectro Hydraulic Controls
Turning Dimensions — Note** Clearance dimensions are for reference only.
Lift/Tilt System - PumpVariable Displacement Piston
Maximum Flow479 L/min
Engine Power - Tier 2/Stage II Engine - ISO 14396:2002333 kW
Relief Valve Setting - Main31700 kPa
Transmission TypeCat switched reluctance electric drive
Lift Cylinder - Bore190 mm
Forward - 1st (virtual)5.8 km/h
Lift Cylinder - Stroke1011 mm
Forward - 2nd (virtual)9.5 km/h
Tilt Cylinder - Bore270 mm
Forward - 3rd (virtual)17 km/h
Tilt Cylinder - Stroke458 mm
Forward - 4th (virtual)24.6 km/h
Forward - 5th (virtual)33.4 km/h
Reverse - 1st (virtual)6 km/h
Reverse - 2nd (virtual)10.1 km/h
Reverse - 3rd (virtual)18 km/h
Reverse - 4th (virtual)26 km/h
Reverse - 5th (virtual)32.9 km/h
Propulsion Motor/Drop Box Oil68 l
Cooling System (Engine Radiator)95 l
Cooling System (Drive Motor - secondary)32 l
Front Differential and Final Drives - With Axle Oil Cooling System140 l
Rear Differential and Final Drives - With Axle Oil Cooling System154 l
