836 Landfill Compactor

Caterpillar

836 Landfill Compactor

رقم القطعة: CAT-120420

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

836 Landfill Compactor

المواصفات

Engine ModelCat® C18
Gross Power - SAE J1995:2014419 kW
Net Power - SAE J1349:2011370 kW
Bore145 mm
Stroke183 mm
Displacement18.1 l
Note (1)* Sound suppression equipped
Note (2)The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
Note (3)The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70% of the maximum engine cooling fan speed.
Note (4)Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas. • If equipped with R134a (Global Warming Potential = 1430), the system contains 1.4 kg (3.1 lb) of refrigerant which has a CO2 equivalent of 2.002 metric tonnes (2.206 tons).
NoteNet power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator.
Fuel Tank793 l
Engine Crankcase60 l
Transmission83 l
Model836
Product Pagehttps://www.cat.com/en_US/products/new/equipment/compactors/landfill-compactors/120420.html
Caterpillar CategoryLandfill Compactors
Caterpillar Category PathProducts > Equipment > Compactors > Landfill Compactors > 836
Caterpillar Product Familyequipment
Caterpillar Product Page ID120420
Datasheet URLhttps://s7d2.scene7.com/is/content/Caterpillar/CM20250929-41655-9b99f
FrontPlanetary – Fixed
Height2260 mm
EmissionsOption 1 - U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V and Japan 2014
Rated Speed1900 rpm
Ground Clearance1730 mm
Engine Power - ISO 14396:2002412 kW
Wheel Base4550 mm
Parking BrakeSpring Applied, Hydraulic Released
Torque Rise52%
Diesel Exhaust Fluid Tank32.8 l
Service BrakesMulti Disc Wet (Enclosed) 2 WHL
Service Refill Capacities — NoteCat U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V and Japan 2014 diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels** up to: • 20% biodiesel FAME (fatty acid methyl ester)*** • 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels • Cat engines meeting Brazil MAR-1 emissions standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA, are compatible with diesel fuel blended with the following lower-carbon intensity fuels** up to: • 100% biodiesel FAME (fatty acid methyl ester)*** • 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. * While Caterpillar engines are compatible with these alternative fuels, some regions may not allow their use. ** Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. *** Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).
Transmission TypePlanetary - Powershift - ECPC
RearPlanetary – Oscillating
Differential - Final Drives - Rear190 l
Differential - Final Drives - Front186 l
Height - Top of Hood3430 mm
Direct Drive - Forward 17 km/h
Direct Drive - Forward 212.6 km/h
Engine — EmissionsOption 2 - Brazil MAR-1, equivalent to U.S. EPA Tier 3/EU Stage IIIA
Direct Drive - Reverse 17.4 km/h
Direct Drive - Reverse 213.2 km/h
Pilot SystemVariable displacement piston
Steering System - CircuitFlow Sharing Implement; Pilot, load sensing
Steering System - PumpPiston – Variable Displacement
Relief Valve Setting - Steering24100 kPa
Total Steering Angle86°
Oscillation Angle±6°
Steering Cycle Times - High Idle3.9 s
Steering Cycle Times - Low Idle6.4 s
Operator Sound Pressure Level (ISO 6396:2008)72 dB(A)
Machine Sound Power Level (ISO 6395:2008)109 dB(A)
Sound Performance - Tier 3 / Stage IIIA — Machine Sound Power Level (ISO 6395:2008)110 dB(A)
Overall Width5193 mm
Hydraulic System - Implement/Steering175 l
Net Power - ISO 9249:2007374 kW
Peak Torque ( 1,400 rpm )3085 N·m
High Idle Speed2120 r/min
Low Idle Speed750 r/min
Operating Weight (Tier 4 Final/Stage V)56275 kg
Pilot Relief Valve Setting3800 kPa
Operating Weight (Tier 3/Stage IIIA equivalent)55939 kg
Cooling Systems - Tier 4 Final/EU Stage V151.5 l
Height - Top of Exhaust Pipe4606 mm
Weight3127 kg
Hydraulic Tank Only103 l
Height to Top of Beacon4634 mm
Ground Clearance to Hitch639 mm
Ground Clearance to Transmission Guard634 mm
Ground Clearance to Bottom of Bumper965 mm
Capacity19.8 m³
Width over Platform3196 mm
Turning Radius – Outside Corner of Blade8737 mm
Total Operating Weight55931 kg
Drum Diameter1770 mm
Drum Width1400 mm
Maximum Altitude - Without Derating2286 m
Maximum Operating Weight (Tier 4 Final/Stage V)57318 kg
Maximum Operating Weight (Tier 3/Stage IIIA equivalent)56982 kg
Lift System - CircuitFlow Sharing Implement; Pilot Operated LS Valve w/EH
Lift System - PumpVariable displacement piston
Max Flow @ 2000 rpm300 L/min
Relief Valve Setting - Lift29000 kPa
Cylinders, Double Acting: Lift, Bore, Stroke137.9 mm x 1021 mm (5.5 in x 40.2 in)
Cooling System - Tier 3/Stage IIIA Equivalent141.1 l
Height of Cutting Edge1125 mm
Height to Top of Air Conditioning Condenser4626 mm
Digging Depth364 mm
Height - Cab Roof4285 mm
Centerline of Rear Axle to Rear Compactor Guard3454 mm
Combination Tips (Weight Group)12814 kg
Hitch to Centerline of Front Axle2275 mm
Plus Tips - Weight (Group)13510 kg
Width over Front Striker Bars3930 mm
Paddle Tips - Weight (Group)12350 kg
Width over Rear Striker Bars3933 mm
Outside Diameter2128 mm
Width over Drums168.5 in
Turning Radius - Inside of Wheels3635 mm
Overall Machine Length with Semi U-Blade10914 mm
Semi U-Blade — Capacity22.4 m³
ReplaceableWeld on
Semi U-Blade — Overall Width5313 mm
Tip Height7 in
Semi U-Blade — Height2294 mm
Semi U-Blade — Height of Cutting Edge1255 mm
Semi U-Blade — Digging Depth362 mm
Semi U-Blade — Ground Clearance1735 mm
Semi U-Blade — Turning Radius – Outside Corner of Blade8823 mm
Turning Radius – Inside of Wheels3635 mm
Semi U-Blade — Weight3612 kg
Semi U-Blade — Total Operating Weight56413 kg
U-Blade — Capacity25.7 m³
U-Blade — Overall Width5290 mm
U-Blade — Height2204 mm
U-Blade — Height of Cutting Edge1255 mm
U-Blade — Digging Depth934 mm
U-Blade — Ground Clearance1198 mm
U-Blade — Turning Radius – Outside Corner of Blade8795 mm
U-Blade — Weight3491 kg
U-Blade — Total Operating Weight56287 kg
Diamond Tips Weight (Group)14814 kg
Outside Diameter - Diamond2140 mm
Feet Per Row8
Feet Per Wheel40
Tip Height - Diamond184 mm
