3512B (50 Hz) Generator Set

Caterpillar

3512B (50 Hz) Generator Set

رقم القطعة: CAT-124000

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

3512B (50 Hz) Generator Set

المواصفات

Engine Model3512B TA, V-12, 4-Stroke Water-Cooled Diesel
Bore170 mm
Stroke215 mm
Displacement58.6 l
Model3512B (50 Hz) 1600 - 1875 kVA
Product Pagehttps://www.cat.com/en_US/products/new/power-systems/electric-power/diesel-generator-sets/124000.html
Caterpillar CategoryDiesel Generator Sets
Caterpillar Category PathProducts > Power Systems > Electric Power > Diesel Generator Sets > 3512B (50 Hz) 1600 - 1875 kVA
Caterpillar Product Familypower-systems
Caterpillar Product Page ID124000
AspirationTA
Voltage380 to 415 Volts
Frequency50 Hz
Speed1500 rpm
Fuel SystemElectronic Unit Injection
Standby Rating1875/1750 kVA
Prime Power Rating1700/1600 kVA
Emissions/Fuel StrategyLow Fuel, Low Emissions
Duty CycleStandby, Mission Critical, Prime
Compression Ratio15.5:1 HD
Governor TypeADEM™ A3
Length - Maximum5709 mm
Width - Maximum2286 mm
Height - Maximum2420 mm
Dry Weight - Genset (maximum)12307 kg
Width - Minimum2286 mm
Height - Minimum2420 mm
Dry Weight - Genset (minimum)12307 kg
Length - Minimum5709 mm
Maximum Rating1875 kVA
Minimum Rating1600 kVA
Stroke - HD215 mm
Displacement - HD58.56 l
