MEC500 - Mobile Equipment Charger

Name: MEC500 - Mobile Equipment Charger
Brand: Caterpillar
SKU: CAT-112964

رقم القطعة: CAT-112964

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

MEC500 - Mobile Equipment Charger

Model	MEC500
Product Page	https://www.cat.com/en_US/products/new/power-systems/electric-power/mobile-equipment-charger/112964.html
Caterpillar Category	Mobile Equipment Charger
Caterpillar Category Path	Products > Power Systems > Electric Power > Mobile Equipment Charger > MEC500
Caterpillar Product Family	power-systems
Caterpillar Product Page ID	112964
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20240920-a8b5a-49e02
Rated Power (AC Input)	500 kW
Voltage Range (AC Input)	400-660 VAC
Frequency Range	50 or 60 Hz
Input Supply (AC Input)	3-Phase Insulated Terra (IT)
Voltage Output	300-1,000 VDC
Rated Current (DC Output)	700 Amps
Cable Output - Cat Proprietary Connector	700 Amp
Ambient Operating Temperature Range	-25° to +50° C (-13° to 122° F)
Storage	-40° to +80° C (-40° to +176° F)
Control Interface	CAN
Control Type	IEC 61851-23/24 (with CAN)
Compliance and Safety	CSA M421; UL2202 (under development)
MEC500	1656 kg
MEC500 with Optional Skid	2037 kg
