C1.1 NA and T China Nonroad IV

Caterpillar

C1.1 NA and T China Nonroad IV

رقم القطعة: CAT-115180

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

C1.1 NA and T China Nonroad IV

المواصفات

Bore77 mm
Stroke81 mm
Displacement1.13 l
ModelC1.1 China NR4
Product Pagehttps://www.cat.com/en_US/products/new/power-systems/industrial/industrial-diesel-engines/115180.html
Caterpillar CategoryIndustrial Diesel Engines
Caterpillar Category PathProducts > Power Systems > Industrial > Industrial Diesel Engines > C1.1 China NR4
Caterpillar Product Familypower-systems
Caterpillar Product Page ID115180
Datasheet URLhttps://s7d2.scene7.com/is/content/Caterpillar/CM20210827-3e20c-d5204
Height588 mm
EmissionsChina Nonroad Stage IV
Rated Speed2400 rpm
Width513 mm
AspirationNaturally Aspirated (NA)/Turbocharged (T)
Maximum Torque86 Nm @ 1600 rpm
Length500 mm
Compression Ratio22.1:1
Rotation from Flywheel Endcounterclockwise
Maximum Power18.4 kW
Minimum Power18.4 kW
Engine ConfigurationIn-line-3
Combustion Systemindirect injection
Weight - Net Dry - Basic Operating Engine Without Optional Attachments96 kg
Total Lubricating Oil Capacity4.4 l
