CV117 Vibratory Drum Compactor

Name: CV117 Vibratory Drum Compactor
Brand: Caterpillar
SKU: CAT-17763645

رقم القطعة: CAT-17763645

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

CV117 Vibratory Drum Compactor

Model	CV117
Product Page	https://www.cat.com/en_US/products/new/attachments/compactors/vibratory-drum-compactors/17763645.html
Caterpillar Category	Vibratory Drum Compactors
Caterpillar Category Path	Products > Attachments > Compactors > Vibratory Drum Compactors > CV117
Caterpillar Product Family	attachments
Caterpillar Product Page ID	17763645
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20230305-3663e-c33fd
Height	634 mm
Length	1009 mm
Overall Width	1854 mm
Weight	936 kg
Drum Diameter	634 mm
Drum Width	1676 mm
Optimal Hydraulic Flow	42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure	145-235 bar (2100-3400 psi)
Required Hydraulics	Standard Flow
Drive Method	Gear Motor - Direct
Drum Frequency at Maximum Flow	2,946 vibrations/minute
Drum Oscillation Tilt Range	± 15 degrees
Dynamic Force	5399 kg
Amplitude	1.15 mm
Motor Size	28 cm³
