Tilting Dual Lock Pin Grabber Coupler For 5 Ton Mini Excavators
رقم القطعة: CAT-100740
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Tilting Dual Lock Pin Grabber Coupler For 5 Ton Mini Excavators
المواصفات
| Model | 5 Ton Mini Excavators Tilting Dual Lock Pin Grabber |
|---|---|
| Product Page | https://www.cat.com/en_US/products/new/attachments/couplers-excavator/tilting-dual-lock-pin-grabber-couplers-mini-excavator/100740.html |
| Caterpillar Category | Tilting Dual Lock™ Pin Grabber Couplers - Mini Excavator |
| Caterpillar Category Path | Products > Attachments > Couplers - Excavator > Tilting Dual Lock™ Pin Grabber Couplers - Mini Excavator > 5 Ton Mini Excavators Tilting Dual Lock Pin Grabber |
| Caterpillar Product Family | attachments |
| Caterpillar Product Page ID | 100740 |
| Overall Height | 546 mm |
| Hydraulic Flow | 7.6-15.1 lpm (2-4 gpm) |
| Length | 574 mm |
| Overall Width | 298 mm |
| Weight | 116 kg |
| Interface Type | Pin On |
| Required Hydraulics | Dedicated Factory Installed |
| Tilt Angle Range | 90° Left/Right |
| Drive Method | Helical Rotary Actuator |
| Machine Class | 5 Ton Mini Excavators |
| Pin Diameter | 45 mm |
| Hydraulic Pressure - Actuator | 207 bar |
| Hydraulic Pressure - Coupler | 252 bar |
