LR119 Landscape Rake

Caterpillar

LR119 Landscape Rake

رقم القطعة: CAT-17765296

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

LR119 Landscape Rake

المواصفات

ModelLR119
Product Pagehttps://www.cat.com/en_US/products/new/attachments/rakes/landscape-rakes/17765296.html
Caterpillar CategoryLandscape Rakes
Caterpillar Category PathProducts > Attachments > Rakes > Landscape Rakes > LR119
Caterpillar Product Familyattachments
Caterpillar Product Page ID17765296
Datasheet URLhttps://s7d2.scene7.com/is/content/Caterpillar/CM20140213-35721-07501
Height989 mm
Length1620 mm
Overall Width1990 mm
Weight653 kg
Optimal Hydraulic Flow42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure145-235 bar (2100-3400 psi)
Required HydraulicsStandard Flow
Working Width1883 mm
Motor Displacement315 cm³/rev
Drive MethodChain Reduction
Bucket Capacity - Struck0.34 m³
Raking Width1665 mm
Driven Shaft Speed165 rpm @ 80 L/min (21 gpm)
Number of Hard Face Tines444
Rock Size Range19-152 mm (0.75-6 in)
Drive Chain#80H
Conveyor Chain#2060H
